- Page 1 SS20 CLASSIC SCANNER ASSEMBLY MANUAL This manual outlines the steps to assemble the Size Stream Classic SS20 3D Body Scanner. FEBRUARY 21, 2020 SOFTWARE V6.0 SizeStream.com 223 Commonwealth Court 919.650.2525 Cary, NC 27511 info@sizestream.co...
-
Page 2: Table Of Contents
Classic Assembly Manual Table of Contents ASSEMBLE THE TOOLS NEEDED: ....................................3 SCANNER LOCATION REQUIREMENTS: ..................................3 UNPACK THE CRATE ........................................4 PLACING THE SCANNER CARPET....................................5 LOWER RIGHT CONNECTOR BAR & FRONT SENSOR ASSEMBLY ............................ 5 LOWER LEFT CONNECTOR BAR...................................... 6 BACK-SENSOR ASSEMBLY. - Page 3 Classic Assembly Manual SCANNER’S COMPUTER ......................................14 ROUTING THE SENSOR CABLES ....................................16 CONNECTING POWER ........................................17 ALIGNMENT BOARD STORAGE ..................................... 19 SCANNER ALIGNMENT BAR ......................................20 CURTAIN TRACK ........................................... 21 FRAME CURTAIN ........................................... 22 HANG THE DRESSING ROOM CURTAIN..................................23 COMPLETED.
-
Page 4: Assemble The Tools Needed
Classic Assembly Manual Tools Needed: Important Drill with #2 and #3 size Phillips screwdriver bits or a manual Phillips screwdriver 7/16” wrench or an adjustable wrench or pliers Do not assemble the scanner Utility knife or pair of scissors alone. Two people are Stepladder. -
Page 5: Unpack The Crate
Classic Assembly Manual Unpack the Crate… Remove all parts and components from the crate. Review parts and components against the provided packing list. Remove the step-by-step hardware set from the accessory box. -
Page 6: Placing The Scanner Carpet
Classic Assembly Manual Placing the Scanner Carpet 1. Position the carpet where the scanner will be located. 2. Orient the carpet so the footprints will be facing the computer pan. Lower Right Connector Bar & Front Sensor Assembly 1. Use four (4) ¼-20 x 5” Pan Head Machine Screws to attach the Front Sensor Assembly to the Lower Right Connector Bar. -
Page 7: Lower Left Connector Bar
Classic Assembly Manual Lower Left Connector Bar Assembly. 1. Use four (4) ¼-20x5” Pan Head Machine Screws to attach the Lower Left Connector Bar to the Front Sensor Assembly Lower Left Connector Bar Hardware Name 1/4-20 x 5” Pan Head Machine Screw ”... -
Page 8: Back-Sensor Assembly
Classic Assembly Manual Back-Sensor Assembly. 1. Use four (4) ¼-20 x 5” Pan Head Machine Screws to attach the Back-Sensor Assembly to the Lower Right Connector Bar. Back Sensor Assembly Hardware Name 1/4-20 x 5” Pan Head Machine Screw Lower Right Connector Bar ”... -
Page 9: Upper Left Connector Bar
Classic Assembly Manual Upper Left Connector Bar 1. Use six (6) ¼-20 x 5” Pan-Head Machine Screws to attach the Front and Back Sensor Assemblies to the Upper Left Connector Bar. Upper Left Connector ASSEMBLY TIP ASSEMBLY TIP To facilitate routing of the sensor The shorter section of the connector bar attaches to the cables through the frame to the... -
Page 10: Upper Right Connector Bar
Classic Assembly Manual Upper Right Connector Bar 1. Use six (6) ¼-20 x 5” Pan Head Machine Screws to attach the Front and Back Sensor Assemblies to the Upper Right Connector Bar. ASSEMBLY TIP To facilitate routing of the sensor Upper Right cables through the frame to the Connector... -
Page 11: Right & Left Handhold Bars
Classic Assembly Manual Right & Left Handhold Bars 1. Use four (4) ¼-20 x 5/8” Pan Head Machine Screws and Washer Nuts to attach the Right-Side Handhold Bar to the Upper and Lower Right Assembly Bar. 2. Make sure the four screws are tightened and the Right Handheld bar is secured to the Upper and Lower Right Assembly Bar. Right Side Hardware Name Handhold... - Page 12 Classic Assembly Manual 3. Use four (4) ¼-20 x 5/8” Pan Head Machine Screws and Washer Nuts to attach the Left Side Handhold Bar to Upper Left and Lower Left Assembly Bar. 4. Make sure the four screws are tightened and the Right Handheld Bar is secured to the Upper and Lower left Assembly Bar. 5.
-
Page 13: Handhold Assembly
Classic Assembly Manual Handhold Assembly 1. Remove the Upper Rubber Bumper on the Right and Left Handhold Slider Bar. 2. Slide the Left Handhold Assembly on to the Left Handhold Slider bar with the handhold facing in the scanner. 3. Slide the Right Handhold Assembly on the Right Handhold Slider bar with the handhold facing in the scanner. -
Page 14: Installing The Monitor
Classic Assembly Manual (opt) Portrait View Installing the Monitor. Rotate the monitor 90 degree and re-secure the Remove the monitor from the box four M4 X 20mm screws Screw four (4) M4 x 20mm screws into the back of the monitor Connect the Power cable, USB cable, and HDMI cable to the back of the monitor. -
Page 15: Scanner's Computer
Classic Assembly Manual Scanner’s Computer 1. Remove the computer from the box. 2. Place the computer in the computer pan. 3. Route all cables up and over the top of the computer. 4. Use four (4) ¼-20 x 5/8” Pan Head Machine Screws to secure the computer to the pan. Hardware Name 1/4-20 x 5/8”... - Page 16 Classic Assembly Manual Unscrew the cover screw on top of the cover panel. Slide the panel up to remove it from the computer. Route the speakers USB cable and stereo jack through the opening at the top of the computer Re-secure the panel to the computer with the cover screw.
-
Page 17: Routing The Sensor Cables
Classic Assembly Manual Routing the Sensor Cables 1. Use a ladder to get to the Sensor’s USB cables located on the Back & Front Sensor Assembly. 2. Route the Front Sensor Assembly’s USB cables through top opening of the computer pan. 3. -
Page 18: Connecting Power
Classic Assembly Manual Connecting Power 1. Connect the Power Extension to the Power Y splitter 2. Connect the Power Y splitter to the computer. 3. Check the computer AC power switch next to the AC power plug. (“O” = power is OFF, “¬” = power is ON). NOTE Ground yourself to discharge any electrostatic... - Page 19 Classic Assembly Manual The Scanner main AC Power connector is located on the Front Lower-Right Corner. Remove the plastic cover and extract the AC power cable. (universal computer connector) Attach the AC power cable to any standard computer cable for your location. NOTE The computer &...
-
Page 20: Alignment Board Storage
Classic Assembly Manual Alignment board storage Unscrew the nut from the Alignment Plane Storage Studs. Be careful that the plastic cover doesn’t fall off. There are two (2) holes located in front of the scanner above the computer pan. Insert the Studs and secure it with the nut. Hang the Alignment Plane on the Alignment Plane Storage Stud. -
Page 21: Scanner Alignment Bar
Classic Assembly Manual Scanner Alignment Bar Located the two (2) pre-drilled holes on the center of the Upper Right & Left Assembly Bar. Use four (4) 8-18 x ½” self-drilling screws to attach the Alignment Bar to the Upper Right & Left Assembly Bar. NOTE Do not fully tighten the screws until the Alignment bar is... -
Page 22: Curtain Track
Classic Assembly Manual Curtain Track Locate the two (2) pre-drilled holes on the Left & Right Front & Back Sensor Assembly Use four (4) 8-18 x 1 ½” self-drilling screws to attach the curtain track to the top of the scanner frame. Hardware Name 8-18 x 1 ½”... -
Page 23: Frame Curtain
Classic Assembly Manual Frame Curtain 1. The hook & fastener tape is pre-cut to fit the scanner. Arrange the tape before applying it to the scanner. 2. Start from the upper left side of the door frame, attach the tape and move around the frame. 3. -
Page 24: Hang The Dressing Room Curtain
Classic Assembly Manual Hang the Dressing Room Curtain. 1. Remove the dressing room curtain from the box. 2. Hang the dressing-room curtain on the curtain carrier hooks. Completed. This concludes the assembly process of the Size Stream SS20 Body Scanner.
