Summary of Contents for MORI ETH-600
- Page 1 Electric tea ETH-600 harvester ISO 9001: 2000 Rev. 2021/05/10 Before using the electric tea picker, please read the following instructions carefully to ensure safe operation！...
- Page 2 Contents 1. Symbol description and precautions 6. Instructions for harvesting tea 2. Safety rules 7. Maintenance 3. Technical Information 4. Installation instructions for spare parts 5. Basic Operation Instructions Symbol description and precautions must read and follow the operation manual before use. Wear qualified and protective earmuffs and goggles Wear qualified and protective gloves Wear protective boots with strong and durable operation...
- Page 3 2. Safety rules Before using this machine *Please read the operation manual carefully. *Please check and maintain the machine in a flat place to avoid moving or dropping the machine. *Check the correct assembly and adjustment of the cutter. *Ensure that any failure has been repaired. *Check clothing and protective equipment (safety helmet, goggles, safety shoes, gloves, earplugs, etc.
- Page 4 3. Technical information Specification IItem One man tea harvester Model no. ETH-600 Vvoltage 36 VDC Weight ( without battery ) 4.6 kgs RPM ( motor ) 8500 /min Llength 870 mm Length of blade 590 mm battery：6.3Ah Continuous operating time 30~40 minutes battery：25.2Ah...
- Page 5 4. Installation instructions for spare parts Installation of leaf bag The mesh of the leaf-collecting bag faces upwards, the lower half of the opening is stuffed into the sheet metal. Use four bag hooks to fix, and tie the belt tightly to avoid leaf collecting bag (Figure 1) falling off.
- Page 6 6. Basic operation instructions 1. connect the battery cable to the machine and tighten the nut (Figure 2). 2. turn on the power switch (Figure 3). 3. Press and hold the safety device to press the throttle lever. 4. The user can change the speed by using 2 speed switch 5.
- Page 7 8. Maintenance For blade 1. Clean the blade with a clean cloth after usage. 2. Please use lubricating oil to lubricate the blade before and after each usage. Please replace the blade, if the blade gap is too large to cut. Adjustment of air hose Please check the air hose is in the correct position If the picked leaves are blocked by the machine or have bad cutting sections...
- Page 8 Records of maintenance TEAM MACHINERY CO., LTD. / TMC No. 209, SHEN AN ROAD, CHANG HWA CITY, TAIWAN, R.O.C. TEL:+886-4-7373668 FAX:+886-4-7371618 MFG ID : 28643855 E-mail : sales@trimmer.com.tw URL : www.trimmer.com.tw TMC MORI © 1997-2008 Team Machinery Co., Ltd. All Rights Reserved...
