SFORZATO DSP-030EX User Manual
1. Display is format and input only.
You cannot switch between title, artist etc. It is displayed on smartphone or tablet.
You can off the display by press and hold «Рhase» (left) button.
2. New model has no default volume setting.
Volume is always pre-installed 100% when player switch-on.
After which it can be adjusted. And then the set volume value is saved during further work.
3. All setting can be changed only with front buttons.
New models DSP has no web browse menu.
The setting by front buttons is remembered
Index
1. Warning
2. Connection Instructions
3. PC Software Installation
4. iPhone / iPod Software Installation
5. Operation Instructions
6. Clock
7. Front Switch
8. Configuration
9. Software Update Instructions
10. Update Log
Included Items
Please check to see if the following items are included.
１）DSP-030EX Main Body
２）DSP-030EX Power Supply Unit
３）2 Cables to Connect the Main Body to the Power Supply
４）AC Cable
５）Isolation Feet
６）User Manual, Safety Pamphlet
1
Ver. 05.31.21
Advertisement
Related Manuals for SFORZATO DSP-030EX
Summary of Contents for SFORZATO DSP-030EX
- Page 1 SFORZATO DSP-030EX User Manual Ver. 05.31.21 1. Display is format and input only. You cannot switch between title, artist etc. It is displayed on smartphone or tablet. You can off the display by press and hold «Рhase» (left) button. 2. New model has no default volume setting.
- Page 2 For detailed connection instructions, refer to the amp manual. ⑥ Connect the LAN cable to the LAN port on the back of the DSP-030EX main body and connect the DSP-030EX to your home LAN network. If you use DELA or fidata for NAS, you can connect directly to the NAS.
- Page 3 ⑨ Turn the clock power on and then turn the DSP-030EX power on. Only connect or disconnect the clock when the DSP-030EX power is off. If the clock is connected or disconnected while the DSP-030EX power is on, a large noise may be made.
- Page 4 NAS manual. ２)Ripping Software To play back CDs on DSP-030EX, you must load the CD data to your PC and store it on the NAS. Loading CD data to your PC is called ripping, and ripping software is used for this procedure.
- Page 5 Also, dBpoweramp can edit information for DSD data. 4. iPhone / iPod Software Installation You can control DSP-030EX remotely using your iPhone or iPod. To do so, you must install remote control software on your iPhone / iPod. We recommend the free app Linn Kazoo / I-O data fidata app. Gapless play back is possible with this app.
- Page 6 ⑤ By playing back music on your PC, sound will be transmitted through DSP-030EX. 3) Configuration Pressing “Select” button on the front panel and hold makes the DSP-030EX go into menu mode. In menu mode, you can change player name, update software and check software version.
- Page 7 For example, DLNARoomName= DSP-AudioRoom:MediaRenderer OpenHomeRoomName= DSP-AudioRoom Then remote control software recognize the DSP-030EX and displays with name of “ DSP-AudioRoom” Insert the USB memory which has the config.txt file to the maintenance connector on the rear panel. Navigate into menu mode of Config File. Press “Phase” button perform the change.
- Page 8 Exit: Pressing “Phase” button in this menu makes the DSP-030EX exit the menu mode and go into normal operation mode. The DSP-030EX is capable to decode MQA files. When MQA streaming is detected in place of PCM there is one of the below options shown: •...
- Page 9 4) Turn on the DSP-030EX> 5) Execute the update software which you unzipped. 6) After PC shows the success, turn off the DSP-030EX and wait 3 seconds and turn it on again. 7) ou can check the software version by navigating the menu mode “Version”.
