Economy Digital Signal Processor
Preface:
Thank you for purchasing our product. Please read this manual to be familiar with the product.
Note:
This manual uses the full function audio processor matrix as an example and can be used as a reference for other
processors.
This manual is only for user operation instructions, not for maintenance service purposes.
This user manual is copyrighted by the manufacturer. No part or all of this manual may be used for commercial
purposes without permission
S H E N Z H E N F H B A U D I O T E C H N O L O G Y C O . , L T D
: 0086-18617093593
: sales@fhbaudio.com
: www.fhbaudio.com
:
No.312, 2712 SongBai Road, LongTeng Community, Shiyan Street, Baoan District, Shenzhen
City, Guangdong, China.518108
User Manual
Advertisement
Table of Contents
Summary of Contents for FHB Audio MX-1616-C
- Page 1 User Manual Economy Digital Signal Processor Preface: Thank you for purchasing our product. Please read this manual to be familiar with the product. Note: This manual uses the full function audio processor matrix as an example and can be used as a reference for other processors.
-
Page 2: Product Description
Product Description Suitable for meeting room, campus, art performance, concert and other scene areas. With a B/S architecture server, access through a web browser, not only to achieve channel control and scenario selection, but also directly provide PC client and platform components download links. ... -
Page 3: Interface Description
Total harmonic distortion + noise(THD+N) ＜0.004% @20-20KHz ,18dBu Ground Noise (A- weighted) -90dBu Delay storage Analog input to output system delay 20KΩ Input impedance (balanced) 100Ω Output impedance (balanced type) Maximum input level +18dBu，Balanced Maximum output level +18dBu，Balanced ≤-131dBU EIN（20-20kHz，A Weighted）. Phantom power supply (per input) 70dB Input common mode suppression，60Hz... -
Page 4: Back Panel
Back Panel： 1) DC12V: DC12V /2A power input interface; (2) PWR: power indicator light, which means the power supply of the equipment is normal; otherwise, the power supply is abnormal; (3) SYS: Status indicator light. The flashing light indicates normal operation of the device; otherwise, the device fails; (4) ETHERNET: 10M/100M ETHERNET interface;... -
Page 5: System Flow
Control: Control channel parameters and enable and disable each processor Scene: Quickly recall and save device scenes. Download: The download link provides the download of the .Net framework PC software. The PC software supports XP, Win7, and Win8 operating systems. Before installing the PC software, please make sure that Microsoft .Net Framework 3.5 or above has been installed on the PC. - Page 6 4) Exit: Close the software. 5) language switching: simplified, traditional and English languages are supported. 3.2 Central Command The central command generator can convert frequently used operations into a 16-character command code to facilitate calls to external devices. Each of these commands contains three different sets of parameters.Control command types: scene, input, output, mix, parameter equalizer, graphic equalizer, expander, compressor, Automatic gain, delay, frequency divider, limiter.
- Page 7 1) User settings a. The initial user name of the device is admin/password 123456, The administrator can add, delete, and modify all user information; ordinary users can only modify personal information. b. Modify user: First select the user to be modified in the user list, the user name and password edit box will display the information of the currently selected user, enter new information, and click the "modify"...
- Page 8 2) Network settings View and modify the network address information of the device, enter the IP address, subnet mask, and gateway in the corresponding position, and click the Apply button to complete the modification...
- Page 9 3) Serial port settings View and modify the serial port information of the current device. Click "Apply" button to modify the serial port information of the current device after setting;If you want to return to the default value, directly click the "All Reset" button, and the items cannot be empty when setting.
-
Page 10: Dsp Module
4) Scene settings a. Modify name: modify the selected scene name. b. Upload scene: upload the scene on the PC side and overwrite the selected scene. c. Save scene: Save the current running parameters to the selected scene. d. Save as: Save the currently running parameters to the PC in a scene. e. - Page 11 Invert: The signal phase is processed by 180 degrees. Phantom power supply: used for condenser microphone power supply, please do not turn on line input or non-condenser microphone to prevent burnt; Test signal: including sine, pink, and white noise. Enabling the test signal system will automatically shield the analog input signal;...
- Page 12 4.3 Compressor The compressor is used to reduce the dynamic range of the signal above a user-defined threshold. The signal level below the threshold remains unchanged. Threshold: When the signal level is higher than the threshold, the gain will be reduced. This point is the inflection point in the input/output curve.
- Page 13 4.4 Equalizer Parameter equalization Pass-through/enable: Whether the equalizer is valid. Band Pass-through/enable: Whether the section equalizer is valid. Center frequency: the center frequency that needs to be equalized. Gain: Gain/attenuation value at the frequency center point. Bandwidth: the influence range of this segment around the center frequency. The larger the value, the larger the bandwidth and the larger the influence range.
- Page 14 4.5 Auto gain The purpose of automatic gain control is to achieve the target level of signals with uncertain levels while maintaining the dynamic range of the volume. Typical usage scenarios: For example, when the user is speaking in front of the microphone, the distance between the mouth and the microphone may be too far and near, which causes the output volume to fluctuate and even feel intermittent in speech.
- Page 15 4.6 Auto Mixer The automatic mixer is mainly used to automatically control how the traditional mixer has a large amount of voice input to output the desired result. Consider a typical conference room scene. There are ten participants, each with a microphone.
- Page 16 4.7 Auto Mixing/AFC/AEC/ANC Feedback: Select the signal to be processed by the feedback canceller, and select the output channel of the processed signal in the mixer. Auto mix: Mix the signal of the selected input channel to the corresponding output channel. AM: Signal processed by the automatic mixer AFC: Signal processed by feedback canceller AEC: Signal processed by echo canceller...
- Page 17 4.9 Frequency Divider High frequency pass/enable: enable and disable the high pass filter. Low frequency pass/enable: enable and disable the low pass filter. High-pass frequency: the cut-off frequency of high-pass filtering. Low-pass frequency: the cut-off frequency of low-pass filtering. 4.10 Limiter Through/Enable: Enable or disable the limiter.
