Summary of Contents for komoder PRIME
- Page 1 USER MANUAL Please read all instructions before using.
- Page 3 USER MANUAL...
- Page 4 15 Use heated surfaces carefully.May cause serious burns.Do not use over insensitive skin areas or in the presence of poor circulation.The unattended use of heat by children or incapacitated persons may be dangerous. SAVE THESE INSTRUCTIONS FOR USE HOUSEHOLD ONLY KOMODER PRIME USER MANUAL...
- Page 5 TECHNICAL SPECIFICATIONS Name: Deluxe Multi-function Massage Chair Model: PRIME Rated voltage: 220-240V~ Rated frequency: 50-60Hz Rated power: 180W Safety design: Class I KOMODER PRIME USER MANUAL...
-
Page 6: Table Of Contents
Step 4: Install the Footrest Unit .......................................22 Position & Placement for Installation .....................................23 Floor Protection ...........................................24 Surrounding Environment .........................................24 Grounding .............................................24 Installation Method ..........................................25 TOUCHSCREEN CONTROLLER USER GUIDE ........................27 HOME SCREEN ....................................27 FUNCTION MENU .................................... 30 KOMODER PRIME USER MANUAL... -
Page 7: Safety Precautions
Do not operate the controller with wet hands or pull the controller wire by force. CAUTION Do not spill water or other liquid into the controller to avoid fault. Do not lay heavy items on the controller. KOMODER PRIME USER MANUAL... -
Page 8: Cautions Regarding The Power Connectors And Power Cord
Do not damage, over bend, pull hard or twist the power cord. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. KOMODER PRIME USER MANUAL... -
Page 9: Troubleshooting
If problem remains, please contact the dealer for maintenance. Important: Do not attempt to repair this product yourself, our company shall not be liable for the injury or damage caused by any servicing without authorization. KOMODER PRIME USER MANUAL... -
Page 10: Care And Maintenance
Do not leave this product exposed to direct sunlight for long periods of time. This may cause fading or damage. Warm Tips During daily use, please check for the following symptoms: Burnt smell. Power flickers on and off when touching the charging cable. The power cord is hot. Other abnormal symptoms. KOMODER PRIME USER MANUAL... - Page 11 Pull out the power cord from the power strips before care and maintenance. To avoid electrical shock or injury,do not touch the power cord with wet hands. Do not try to dismantle or repair the product yourself,please send your massage chair to the authorized service center. KOMODER PRIME USER MANUAL...
-
Page 12: Safety Precautions
Do not put hands or foreign objects in the openings of the appliance to avoid injury to the user or damage to the appliance. If there is any smoke or unusual smell during operation, stop using immediately. KOMODER PRIME USER MANUAL... - Page 13 Never plug in or pull out power cord with wet hand to avoid shock or injury. Pull out the power cord from the power strips after use. UNPLUG Unplug from outlet when the power supply is cut. POWER CORD KOMODER PRIME USER MANUAL...
-
Page 14: Name And Function Of Each Component
Back massage airbags Mobile phone organizer Voice command microphone Back heat USB charging port Waist massage airbags Lower mechanism Arm massage airbags Seat side massage airbags Leg heat Leg massage airbags Foot massage airbags Foot rollers KOMODER PRIME USER MANUAL... -
Page 15: Preliminary Checks
When not in use for a long period of time,we recommend that the chair be covered, the power cord be coiled and that the unit be placed in an environment free of dust and moisture. KOMODER PRIME USER MANUAL... -
Page 16: Commissioning
If there is any part not in default position,please turn off the massage chair to allow it to restore. CAUTION Do not take seat while the legrest is lifted. Do not put excessive load on the legrest to avoid damage. KOMODER PRIME USER MANUAL... -
Page 17: Name And Function Of Each Component
NAME AND FUNCTION OF EACH COMPONENT Control Panel Power/Auto Massage Button Back Down Back Up Feet Down Feet Up Feet Extend Feet Retract KOMODER PRIME USER MANUAL... -
Page 18: Control Panel Instructions
Press and hold to extend the footrest;release the button to stop. (Make sure there is enough clearance in advance) Feet Retract Press and hold to retract the footrest;release the button to stop. Touchscreen Controller User Guide See the “Touchscreen Controller User Guide” at touch screen controller display. KOMODER PRIME USER MANUAL... -
Page 19: Preliminary Checks
Turn on the main power switch by the right hand side of the massage chair. CAUTION Please verify that there is no damage to the supply cord before switching on the massage chair. Please verify that the main power switch is turned off before connecting to power. KOMODER PRIME USER MANUAL... -
Page 20: Step 6: Install Touchscreen Controller Holder
Connect the power cable to the product power socket located at the bottom of right armrest. Connect power to chair, switch ON the power button, use the controller to raise the backrest to fully upright position. Power plug Power connector port Fuse Power switch KOMODER PRIME USER MANUAL... -
Page 21: Functions And Features
9. Striking Flexible Track The track outstretches while the massage chair is reclining,mechanism travel distance increased from 1160mm to 1210mm, delivering three dimensional massage from neck to thighs. KOMODER PRIME USER MANUAL... -
Page 22: Offline Voice Control
Lady massage Senior massage Neck&Shoulder Waist&Buttock Back&Spine Thai massage Ancient massage Pushing massage Turn on foot rollers Turn off foot rollers Turn on heat Turn off heat Turn Off Zero Gravity Zero Gravity one Zero Gravity two KOMODER PRIME USER MANUAL... -
Page 23: Preliminary Checks
Step 5: Install Touchscreen Controller Holder Remove the screw from the socket, install the touchscreen controller holder into the socket and secure with the M4 screw, then put the deco part on the top. KOMODER PRIME USER MANUAL... -
Page 24: Step 3: Install The Speaker Unit
Raise the legrest unit, thread the air hose into the air nozzle, and fit the air valve plug into the air valve port which located at the face side of seat base, make sure they are well secured. hose Air nozzle Footrest drive wire socket connector Footrest drive wire plug connector KOMODER PRIME USER MANUAL... -
Page 25: Position & Placement For Installation
Straighten the power cord while in use to avoid tangle or damage. When the massage chair sliding forwards or back, please check to make sure there are no children, pets or other obstacles around to avoid accident. KOMODER PRIME USER MANUAL... -
Page 26: Floor Protection
Grounding This product must be grounded, the plug must be plugged into an appropriate 3-wire grounded outlet that is properly installed and grounded in accordance with all local codes and ordinances to reduce risk of electrical shock. KOMODER PRIME USER MANUAL... -
Page 27: Installation Method
Connect the numbered air hose to the matching numbered nozzles on the armrest and plug in the connectors. (The plug-in connectors can be matched by colors; Same installation method with the other side.) Armrest unit Air valve plug Air hose Air nozzle Air valve socket KOMODER PRIME USER MANUAL... - Page 28 (Same installation method with the other side) Armrest/headpiece joint connector Plain washerΦ8×14 Armrest unit Hex socket M8×30 screw Spring washer 8 Bracket 2 Bracket 1 Bracket 4 Bracket 3 Screw hole Armrest linkage unit Hex socket M6×20 screw Plain washerΦ6×14 KOMODER PRIME USER MANUAL...
-
Page 29: Touchscreen Controller User Guide
Home Screen may vary depending on the task you’re performing. Menu Auto Manual swipe switch Auto Massage Auto Massage Auto Massage Extension Release Breathe Options Adjustments Settings 3 Featured auto massage programs Home Screen 1 Home Screen 2 KOMODER PRIME USER MANUAL... - Page 30 Tap the program you like to start massage. Running Double tap to body scan Extension 29:59 Resetting... Background Music Speed Air Strength Reset when finished Force Width Feet Soothing Vigorous Gentle 3D Strength Massage Program Running Reset KOMODER PRIME USER MANUAL...
- Page 31 3D Strength: 5 levels and Off (turn off 3D Strength). 3D Strength is not adjustable if 3D Shiatsu is selected. ( Speed: 6 levels. Speed is not adjustable if Shiatsu or 3D Shiatsu is selected. ( KOMODER PRIME USER MANUAL...
-
Page 32: Function Menu
3 levels and Off (turn off Foot Rollers). This option is not adjustable if Full or Legs Airbags is selected. Back Heat: 3 levels and Off (turn off Back Heat). Leg Heat: 3 levels and Off (turn off Leg Heat). KOMODER PRIME USER MANUAL... - Page 33 Tap and hold the icon to lift/lower the massage chair footrest. Knees: Tap and hold the icon to move the upper part of legrest up/down. Feet: Tap and hold the icon to extend/retract the the footrest. KOMODER PRIME USER MANUAL...
- Page 34 FUNCTION MENU Massage programs/Massage chair adjustment/Settings Settings Screen Brightness Settings You can check all settings of the touch screen controller Language in Settings. Tap the icon to see detailed information. Bluetooth Charging KOMODER PRIME USER MANUAL...
