VBOX II Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
01 - VBOX II Front Panel
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/
Discontinued_VBOX_II_versions/User_Guide_VBOX_II_(VB2SX5%2C_VB2SX10%2C_VB20SL3)/01_-
_VBOX_II_Front_Panel
VBOX II units can be configured using the front panel buttons, which enables configuration without the need for a
computer. Configuration can also be made via the
From the main screen, press the'■' button to enter the configuration screen.
Note: Entering the configuration screen will cause the VBOX to stop logging to the SD card. When in
continuous logging mode, please ensure that the '■' button is pushed prior to removing the SD card to avoid
data loss.
Once in the configuration screen, press the '◄'and '►' buttons to highlight the next or previous choice in any menu, and
press '■' to select the highlighted option. Most Main menus contain sub-menus, for example the Settings and Setup
Antennas menus contain separate menus for each parameter.
VBOX Setup
Software.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the II and is the answer not in the manual?

Questions and answers

Summary of Contents for VBOX II

  • Page 1 01 - VBOX II Front Panel https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/ Discontinued_VBOX_II_versions/User_Guide_VBOX_II_(VB2SX5%2C_VB2SX10%2C_VB20SL3)/01_- _VBOX_II_Front_Panel VBOX II units can be configured using the front panel buttons, which enables configuration without the need for a computer. Configuration can also be made via the VBOX Setup Software. From the main screen, press the’■’ button to enter the configuration screen.
  • Page 2 Note: The options highlighted in blue are only available on the SL series units.
  • Page 3 Press ’■’ to enter the VBOX general settings menu. COLDSTART Press ’■’ to perform a GPS cold start Press ’■’ to change the mode of operation between VBOX module mode and Stand Alone mode. MODE Then press ’■’ to confirm.

  • Page 4: Settings Menu

    Press ’■’ to enter the GPS configuration Menu. The Kalman Filter, Dynamic Mode and DGPS mode is configured within this menu. Press’ the ‘◄’ and ‘►’ buttons to set an Time offset in order to align the VBOX time to the users TIME OFFSET Local time.
  • Page 5 Setup Antennas (Pitch Antenna) Press ’■’ and then use the ‘◄’ and ‘►’ buttons to change the antenna separation. Then press ’■’ SEPARATION to confirm. Range is 0.5 – 5.0 m in 0.1 m increments Press’■’ and then use the ‘◄’ and ‘►’ buttons to enable or disable the LEVEL option. With the LEVEL LEVEL set to YES the RTK lock is more resilient.
  • Page 6 Setup Antennas (Roll Antenna)* *VB20SL3 triple antenna units only Press’■’ and then use the ‘◄’ and ‘►’ buttons to change the antenna separation. Then press ’■’ to SEPARATION confirm. Range is 0.5 – 5.0 m in 0.1 m increments Press ’■’ and then use the ‘◄’ and ‘►’ buttons to enable or disable the LEVEL option. With the LEVEL LEVEL set to YES the RTK lock is more resilient.
  • Page 7 Smoothing Menu Press ’■’ and then use the ‘◄’ and ‘►’ buttons to change the amount of smoothing applied to the calculated Lateral Acceleration output. Then press ’■’ to confirm. 0.0 – 5.0 (0.1 steps) Press ’■’ and then use the ‘◄’ and ‘►’ buttons to change the amount of smoothing applied to the LONG calculated Longitudinal Acceleration output.

  • Page 8: Max Value

    Outputs: Digital Setup Menu (Channel 1 and 2) Press ’■’ and then use the ‘◄’ and ‘►’ buttons to associate either of the following channels OUTPUT SPEED, SLIP, PITCH, ROLL, LAT ACC and LONG ACC to the Digital output. Then press ’■’ to confirm.
  • Page 9 Outputs: Analogue Setup Menu (Channel 1 and 2) Press ’■’ and then use the ‘◄’ and ‘►’ buttons to associate either of the following channels SPEED, OUTPUT SLIP or PITCH, ROLL, LAT ACC and LONG ACC to the Analogue output. Then press ’■’ to confirm. Press ’■’...
  • Page 10 EXIT Press ’■’to exit the setup menu and cause the settings to be saved in EEPROM.

  • Page 11: Dynamic Mode

    To perform a factory reset on the unit, if for example the unit is not functioning correctly, press and hold the ’■’ and ‘►’ buttons whilst power is supplied to the VBOX II. The front panel screen will display an 'updating...
