- Page 1 STEREO TO MONO AUDIO CONVERTER PART NUMBER PA-SM21 Converts a stereo line level audio signal to a balanced mono audio output through the 3-pin terminal connecter vanco1.com | 800.626.6445...
-
Page 2: Dear Customer
DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. THIS PRODUCT IS 100% INSPECTED AND TESTED IN THE UNITED STATES TO VERIFY PERFORMANCE PARAMETERS. -
Page 3: Package Contents
FEATURES The PA-SM21 Stereo to Mono Audio Converter can convert a stereo line level audio signal to a balanced mono audio output through the 3-pin terminal connecter. It can also adapt a balanced mono audio signal to an unbalanced mono audio signal using the dual RCA outputs. Small, compact and mountable metal chassis makes it a nice and easy solution when looking to convert your audio signal. -
Page 4: Panel Descriptions
PANEL DESCRIPTIONS Balanced 3-Pin Terminal (Phoenix) Connecter: This can be used as an input to convert a balanced mono INPUT to mono RCA output, or to convert stereo line level signal to a balanced mono output Unbalanced dual-RCA jacks. These can be used as an input to convert a stereo line level signal to a to a balanced mono output, or as an output to convert balanced mono INPUT to dual MONO RCA outputs... -
Page 5: Connect And Operate
- Use dual RCA connectors for an unbalanced stereo audio signal input Connect the PA-SM21 as an output to your amp/pre-amp - Use the 3-conductor wire and the provided phoenix connector to output a balanced mono audio signal... -
Page 6: Technical Support
However, like all electronic equipment, the PA-SM21 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 7: Liability Statement
LIABILITY STATEMENT Every effort has been made to ensure that this product is free of defects. The manufacturer of this product cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. It is the responsibility of the user and installer of the hardware to check that it is suitable for their requirements and that it is installed correctly. - Page 8 ® Vanco International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 | fax: 630.879.9189 visit: www.vanco1.com A brand from Learn more at vanco1.com...
