Summary of Contents for Waves Proton Duo
- Page 1 Waves Proton Duo Quick Start Guide...
- Page 2 Proton Duo This quick start guide provides basic instructions for setting up Proton Duo with a SoundGrid host. Consult your SoundGrid host application’s user guide for detailed instructions concerning configuration. Proton Duo combines a Waves Proton SoundGrid server, an Axis Proton audio-optimized computer, and a built-in 1 Gb network switch, in one compact device.
- Page 3 How to Connect Since Proton Duo combines a host computer, a server, and an Ethernet switch in one package, all that’s left to do is to connect one or more SoundGrid I/Os, add a computer display and, if needed, an external control surface.
-
Page 4: Connections And Controls
Connections and Controls Proton Duo: Front Panel 2x USB 2 ports Power switch and light Hold for five seconds to shut down the Proton Duo completely. Hold for three seconds to reset the host computer. Proton Duo / Quick Start... - Page 5 Do not use these ports for normal operation. The 1 Gb 4-port switch connects to SoundGrid I/Os and other SoundGrid networks. For additional connections, add Waves SoundGrid switch an approved 1 switch. Do not use this port for other purposes. Proton Duo / Quick Start...
-
Page 6: Hardware Connections
To the left of the SoundGrid ports are two USB 3.0 ports and an HDMI port. This is the Service section. If you are experiencing technical problems, a Waves tech support specialist may instruct you connect to these ports for debugging and troubleshooting. - Page 7 All Waves V13 applications, plugins, and drivers are preinstalled on your Proton Duo. Your software license determines which products are available to you. If you keep your Waves licenses on a USB flash drive (“disk on key”), simply insert the drive into a USB port and then open your Waves application. The host will locate the licenses.
- Page 8 • Press and hold the Power button for five seconds to shut down the Proton Duo completely (host and server). • If for any reason the host side is frozen, you can force restart (Reset) the host side of Proton Duo independently from the server.
-
Page 9: Specifications
44.1 kHz, 48 kHz Battery Disposal Information CAUTION Risk of explosion if the battery is replaced with an incorrect type. Batteries should be recycled where possible. Disposal of used batteries must be in accordance with local environmental regulations. Proton Duo / Quick Start...
