UDIZINE Vertik Assembly Instructions

Vertik
For base unit only - see page 2
For multyple units (UP TO 3 UNITS) - see page 3
Base Unit
B2
B1
B1
B3
General Note:
weight of display. It is recommended to consult with a professional and determine the appropriate fastener/anchor needed for the mounting surface. UDIZINE
is solely responsible for the quality of its products and not accountable for faulty installation and ill use of its products beyond recommended limitations.
Assembly Instructions

Floor Stand

31
Slits
Screw
thread on
both ends
Casters
Hardware Provided
Socket Head Screw L 1 1/4" & Washers
Flat Head Screw
Allen Key Set- Metric #
Wrench for M10 washer
L 1 5/8"
Extension Bar Connecting Set
It is the responsibility of the purchaser and/or installer to verify that the mounting surface is solid and capable of supporting the intended
3/4"
Required Shelf Length:
23 7/8"
include edge banding
24 1/2 "
26"
Add-On Unit
E1
Base
4
4
#5 & #6
1
—
4 1/2"
24"
Screw
thread
E2
on one
end only
E3
Add-On
2
—
#4 & #6
1
2
VER_01
Page 1 of 4
