- Page 1 Expert manufacturers of short duration breathing apparatus specialists in escape and working rescue Semmco EEBD Emergency escape oxygen breathing device to protect from: • Smoke • Toxic contamination • Oxygen deficiency...
-
Page 2: Technical Data
As the user exhales into the bag, moisture from • The unit is within the expiry date their exhaled breath activates the KO that then ‘scrubs’ the • The visual indicator is blue and not pink and liberates oxygen. Oxygen continues to be generated while the EEBD is being used and depending on the version If these conditions are not met the unit mustn’t be used deployed, will last for 15 or 20 minutes. and must be replaced with a new unit. Technical Data Temperature inhaled gas 35L/min <50°C Breathing Bag Volume ≥6 litre... - Page 4 Donning the Semmco EEBD 1. 6. Lift yellow clip Take a breath, put neck strap over head 7. 2. Remove lid Insert mouthpiece Remove set from case by pulling Adjust neck strap, fit nose clip, on the base of breathing hose exhale into mouthpiece Remove set from case If needed, don face shield and...
-
Page 5: Regulations And Approvals
Donning the Semmco EEBD Regulations and Approvals Semmco EEBD has been designed and tested in accordance with the following regulations: • EN13794 and ISO 23269-1 – to demonstrate compliance with the essential safety requirements with PPE Regulation (EU) 2016/425 • SOLAS (International Convention For The Safety of Life at Sea) – Emergency Escape Breathing Devices • Marine Equipment Directive 2014/90/EU Approvals – UKCA & CE (Industrial PPE & Marine SOLAS) • Is in conformity with the Merchant Shipping (Marine Equipment) Regulations SI 2016/1025, as amended by SI 2019/470 & MSN 1874 Amend 4 and with the relevant... - Page 6 Semmco LPS Expert manufacturers of short duration Semmco EEBD breathing apparatus - specialists in escape and The latest addition to the escape and working rescue devices working rescue range, the Semmco EEBD is a self-contained, single use, short duration oxygen (O ) breathing device specifically for use Semmco Life Protection Systems specialises in the design and in the Maritime & Offshore, Industrial, Military and Mining manufacture of escape and working rescue breathing devices markets. It is available in the following configurations: to protect those working in irrespirable atmospheres. In such • Marine - 15 minute set critical situations, escape and working rescue breathing devices • Industrial - 20 minute set must be easy to don, simple to use and totally reliable. Unlike the HEAD Devices, it is simpler in design with a...
