Giant -309 Operation Manual (2.4GHz Cordless + CID)
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be followed to reduce
the risk of fire, electric shock and injury to persons, including the following:
1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or
laundry tub, in a wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a
remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire.
They may explode. Check with local codes for possible special disposal instructions.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF
USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
SAVE THESE INSTRUCTIONS
Revision 1
Page 1 of 22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 309 and is the answer not in the manual?

Questions and answers

Summary of Contents for Giant 309

  • Page 1 Giant -309 Operation Manual (2.4GHz Cordless + CID) IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 2: Main Features

    Giant -309 Operation Manual (2.4GHz Cordless + CID) MAIN FEATURES OLYMPIA OL2430 CORDLESS PHONE FEATURES : 1. 2.4GHz 40 channels auto scanning operation 2. Manual channel selection 3. 65536 Random combinations of security code 4. Last number re-dial (32 digits max.) 5.

  • Page 3: Cordless Operation

    Giant -309 Operation Manual (2.4GHz Cordless + CID) 15 Battery low indication (‘Battery Low’ text display on the 3 line ) CORDLESS OPERATION Channel frequencies CH. BASE TX H/S TX BASE TX HS/TX 2401000000 2473500000 2403000000 2475500000 2401100000 2473600000 2403100000...

  • Page 4: Answering Call

    Giant -309 Operation Manual (2.4GHz Cordless + CID) 1. Power Up 1.1. After power up, the handset should place on the cradle of the base unit for setting a new security code for communication 1.2. Each time when the handset place on the cradle of the base unit, the base unit will generate and transmit a new security code to the handset unit through the RF Link.(The both unit will...

  • Page 5: Terminate A Call

    Giant -309 Operation Manual (2.4GHz Cordless + CID) 4. Terminate a call 4.1. To terminate a call, either by pressing the “TALK” button, the handset will emit a beep indicating call is terminated successfully. 4.2. By placing the handset on the cradle, call is terminated and ‘Security code set up’ procedure will be performed.

  • Page 6: R I N G E R O N

    Giant -309 Operation Manual (2.4GHz Cordless + CID) 8. Setting local area code 0 0 0 A R E A C O D E ? 8.1. You need enter 3 digits from number pad. Three digits will be shift to left one by one, after you enter one digit.

  • Page 7: Setting Display Contrast

    Giant -309 Operation Manual (2.4GHz Cordless + CID) 11. Setting handset LED ON/OFF/CON L E D O N 11.1. It will display current “LED ON/OFF/CON” setting first. 11.2. Press “#” or “*” button to set the desired setting, and the display will update to current setting also, ”LED ON”à”...

  • Page 8: Receiving Calls

    Giant -309 Operation Manual (2.4GHz Cordless + CID) Display Descriptions Remarks 12-character text line For display of callers’ name, system prompts (CID Dot-matrix and phone), call timer, dial number. (5 x 5 ) 12-digit number line 1, Display caller’s number (CID), or 7-segment 2, Display dialed digits (phone).

  • Page 9: N O C A L L E R I D

    Giant -309 Operation Manual (2.4GHz Cordless + CID) NEW CALL 10:00 1 1/0 1 CALL CALL   13.1.2. The display also indicates if caller information is not available or if the sender intentionally blocks the number. 1 0/3 0 10:00...
  • Page 10 Giant -309 Operation Manual (2.4GHz Cordless + CID) 13.2.3. If the received call information is same as any of the existing new calls, the ‘RPT’ icon will be on to indicate REPEAT CALL. The most recently arrived CID will be saved attached with a new date / time stamp.
  • Page 11 Giant -309 Operation Manual (2.4GHz Cordless + CID) 13.4. DELETE INDIVIDUAL CALL 13.4.1. When you review the call information, you can delete it from the display.Press “#” or “*” button until the call record you want to delete. 10:00 1 0/3 0...
  • Page 12 Giant -309 Operation Manual (2.4GHz Cordless + CID) ring, and VIP icon will be on. 13.6.1. Press “#” or “*” button to select the caller to which you want to assign a VIP. 13.6.2. Press and hold “Calls” button for 2 seconds , the VIP icon is on.
  • Page 13 Giant -309 Operation Manual (2.4GHz Cordless + CID) 13.7.4.2. If a 10 digits long CID number (123-456-7890), the first 3 digits of the number matches local area code, the area code will be skipped and only the last 7 digits will be dialed out in the re-dialing.
  • Page 14 Giant -309 Operation Manual (2.4GHz Cordless + CID) No press any button for 20 seconds, it will return stand-by mode. 14. Visual message function When Visual message function is activated, the Telephone Company sends the Visual message information out accordingly. The device receives and displays this information for each Visual message.
  • Page 15 Giant -309 Operation Manual (2.4GHz Cordless + CID) 15.2.2. You enter number, the display will shift entered digits from right to left-hand side until the number reach to 16 digits. If the number is larger than 16 digits, error tone will be generated.
  • Page 16 Giant -309 Operation Manual (2.4GHz Cordless + CID) 2 3 4 5 6 7 8 9 9 9 9 0 M E M 2 15.2.3. Press “Del” button to delete the last entered digit. The display will shift entered digits from left to right-hand side.
  • Page 17 Giant -309 Operation Manual (2.4GHz Cordless + CID) No press any button for 20 seconds, it will return stand-by mode. 15.5. Dial indirect memory ( TALK ON ) 15.5.1. Press “TALK” button to enter TALK-ON mode. The display will show ‘TALK 0:00’.

  • Page 18: Dialing Digits

    Giant -309 Operation Manual (2.4GHz Cordless + CID) 16.3. Press “Flash” button to clear all entered digits and it will return to stand-by. 16.4. Press “Calls” button, The unit will enter TALK-ON mode automatically. The number will scroll across the screen from right to left-hand side as it is dialed.

  • Page 19: Call Timer

    Giant -309 Operation Manual (2.4GHz Cordless + CID) ‘*’ will be displayed as ‘ ’ in line2, ‘*’ in line3 PAUSE will be displayed as ‘P’, when PAUSE is encountered during dialing, a pause of 4 seconds will be generated.

  • Page 20: Changing Volume

    Giant -309 Operation Manual (2.4GHz Cordless + CID) 21. Mute 21.1. Press and hold “Mute” button to mute audio in TALK ON mode. 22. Changing Volume User can adjust the volume levels (3 levels) in talk mode. Pressing “Del” key to increase or “Calls”...
  • Page 21 Giant -309 Operation Manual (2.4GHz Cordless + CID) Consumer Information: This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the back of this equipment is a label that contains, among other information, a product identifier in the format US:DDKW900BOL2430.

  • Page 22: Translation Table

    Giant -309 Operation Manual (2.4GHz Cordless + CID) Industries, with the below information for warranty information. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.
