VOYAGER
QUICK START
HOW TO USE YOUR
VOYAGER SKI
IMPORTANT NOTE: Before first use
visit your local Elan certified dealer
for binding adjustment.
All operations regarding folding and
unfolding of Voyager ski are toolless.
Do not use excessive force while
assembling or disassembling skis,
all steps are easily performed.
01
Slide the lever with your thumb towards the
binding and lift with the index finger.
1
SLIDE
TOE
02
Unfold the skis.
03
Rotate the binding plate and
align it with the skis.
ROTATE & ALIGN
04
Slide the lever with your thumb towards the
binding and press it down.
2
1
SLIDE
TOE
05
Press the brake pedal firmly and move the lever
down to the horizontal position.
PRESS AND HOLD
THE BRAKE PEDAL
LEVER DOWN
HEEL
LIFT
2
PRESS
1
2
MOVE THE
LIFT
HEEL
UNFOLD
2
HEEL
SLOWLY RELEASE
THE BRAKE PEDAL
HEEL
www.elanskis.com
2
1
SLIDE
PRESS
1
SLIDE
