ELECTRIC TOY CAR
Important
Warning!
1. Not Suitable for children under 36 months
2.
Choking hazard due to small parts
3.
For family and domestic use only
Age: 3+Years
4.
Not to be used in traffic
Maximum user
5.
Adult assembly required
weight :20Kg
6.
Protective equipment should be worn
Please keep this manual for future reference as it contains important information.
Before first time use, charge the battery for at least 8-12 hours under adults surpervision,
but no more than 20 hours.
FOR ANY PRODUCT ENQUIRIES OR ISSUES PLEASE CONTACT HUNTER PRODUCTS
AT WWW.ELECTRICRIDEON.COM.AU OR TOLL FREE HELP LINE 1800 224 094.
Model No.: ZPV
Item No.: HUN0336
118A
Advertisement
Related Manuals for Hunter Products ZPV118A
Summary of Contents for Hunter Products ZPV118A
- Page 1 Before first time use, charge the battery for at least 8-12 hours under adults surpervision, but no more than 20 hours. FOR ANY PRODUCT ENQUIRIES OR ISSUES PLEASE CONTACT HUNTER PRODUCTS AT WWW.ELECTRICRIDEON.COM.AU OR TOLL FREE HELP LINE 1800 224 094.
- Page 2 DIRECTORY BEFORE USE SPECIFICATION PRECAUTIONS PARTS EXPLODED DIAGRAM ASSEMBLY DIAGRAM P5-P6 OPERATION AND FUNCTION FUSE ( I ) CHARGING AND BATTERY SAFETY CARE AND MAINTENANCE TROUBLESHOOTING GUIDE (A) BEFORE USE Please read the product manual carefully before use. Please follow the detailed installation guide and follow the correct procedures to avoid potential damage or injury which may be caused due to improper use.
- Page 3 (C) PRECAUTIONS WARNING: ADULT ASSEMBLY REQUIRED. Read all instructions carefully before assembling this product. WARNING: ASSEMBLY · Keep these instructions for future reference. · Prior to assembly, this package contains small parts: hardware which is a choking hazard and may contain sharp edges and sharp points. Keep product away from children until assembled.
- Page 4 Before first time use, charge the battery for at least 8-12 hours under adults surpervision, but no more than 20 hours. FOR ANY PRODUCT ENQUIRIES OR ISSUES PLEASE CONTACT HUNTER PRODUCTS AT WWW.ELECTRICRIDEON.COM.AU OR TOLL FREE HELP LINE 1800 224 094.
- Page 5 (E) EXPLODED DIAGRAM...
- Page 6 (F) ASSEMBLY DIAGRAM 1.Install each part in sequence on the front and rear axles as shown in the drawing, then tighten the nuts with a wrench, and finally attach the hub card. 2.Remove the bolt & nut from the steering wheel, insert steering wheel into the steering rod and fix the bolt &...
- Page 7 3.As shown in the picture, first remove the seat cushion, connect the motor plug and the motor connector. insert the black plug-in on the battery inside the car body into the battery, and then install the seat cushion.
- Page 8 (G) OPERATION AND FUNCTION （1）The vehicle has a horn. （2）When the normal driving speed of the vehicle is obviously slow, it should be charging in time, charging for 8-12 hours.No continuously charging over 20 hours, the charger has a slight heat phenomenon, which is normal.
- Page 9 (H) FUSE The vehicle use self-tapping fuse.When overloading or improper use, the fuse will be automatically cut off in 10-20 seconds.and then will automatically connect the power. To avoid the cutting off,please pay attention: (1). The maximum weight limited of the motorcycle is 20KG. (2).
- Page 10 (J) CARE AND MAINTENANCE (1) An adult should regularly check things such as plugs, electrical, housing and steering systems. If fastenings are in normal working order, It is suggested these checks are done every two weeks. If there are any problems, STOP use immediately until the issues are resolved and the unit is back in working order.
- Page 12 Competition and Consumer Act 2010 (Commonwealth), and any other statutory rights to which you may already be entitled, and this warranty does not exclude, restrict or modify any such rights or remedies that are implied by law. HUNTER PRODUCTS 233 Bay Street, Brighton, Victoria 3186 Ph: 1800 224 094 Email: enquiries@hunterproducts.com.au...
