6.0 inch
E-paper Display Series
GDE060BAFL-T
Dalian Good Display Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GDE060BAFL-T and is the answer not in the manual?

Questions and answers

Related Manuals for Good Display GDE060BAFL-T

Summary of Contents for Good Display GDE060BAFL-T

  • Page 1 6.0 inch E-paper Display Series GDE060BAFL-T Dalian Good Display Co., Ltd.
  • Page 2 GDE060BAFL-T Product Specifications Customer Standard 6.0” E-PAPER DISPLAY with Description Touch Panel and Frontlight Model Name GDE060BAFL-T Date 2019/04/26 Revision Design Engineering Approval Check Design No.17 Gonghua Street, Shahekou District, Dalian 116021 China Tel: +86-411-84619565 Fax: +86-411-84619585-810 Email: info@good-display.com Website: www.e-paper-display.com www.e-paper-display.com...

  • Page 3: Table Of Contents

    GDE060BAFL-T Contents 1 General Description ................ 5 2 Features ..................5 3 Application ..................5 4 Pin Assignment................6 5 Electrical Characteristics ..............7 6 Power On/Off Sequence ..............10 7 Mechanical Specifications ..............11 8 Optical Characteristics ..............13 9 Handling, Safety and Environment Requirements .........
  • Page 4 GDE060BAFL-T Version Content Date Producer New Release 2019/04/26...

  • Page 5: General Description

    GDE060BAFL-T 1 General Description GDE060BAFL-T is an Active Matrix Electrophoretic Display(AM EPD) with touch panel and frontlight, High-Resolution AM TFT Black/White display module which can be used in portable electronic devices, such as E-book Reader. The module is a TFT-array driving electrophoretic display, with integrated circuits including source and gate drivers.

  • Page 6: Pin Assignment

    GDE060BAFL-T 4 Pin Assignment Pin Name Description VNEG Negative power supply source driver Negative power supply gate driver Ground NO Connection NO Connection Digital power supply drivers Ground Clock source driver Ground Latch enable source driver Output enable source driver...

  • Page 7: Electrical Characteristics

    GDE060BAFL-T 5 Electrical Characteristics 5.1 Module Interface Description This module can be driven by ASIC AVT6201A Timing Controller(T-Con). 5.2 Module DC Characteristics Parameter Symbol Conditions Unit Signal ground Logic Voltage supply IVDD VDD=3.3V Gate Positive supply 0.35 IVGH Gate Negative supply -3.0...
  • Page 8 GDE060BAFL-T 5.3 Module AC Characteristics Note:VDD=3.0V to 3.6V, unless otherwise specified Parameter Symbol Min. Typ. Max. Unit App Pin Clock frequency fcpv Clock CPV high time tCPVh Clock CPV low time tCPVl Data setup time Data hold time Clock CLK cycle time tclk D0 ..
  • Page 9 GDE060BAFL-T Clock & Data Timing tclk D0~D7, SPH Output Latch/Control Signals tLEdly tLEoff tLEw tMsu tCPVl tCPVh www.e-paper-display.com 6.0 inch Series...

  • Page 10: Power On/Off Sequence

    GDE060BAFL-T 6 Power On/Off Sequence To prevent the device from damage due to latch up, the power on/off sequence shown below must be followed. When power on: VDD -> VGL -> VNEG/VGH/VPOS -> Vcom When power off: Vcom -> VNEG/VGH/VPOS -> VGL -> VDD...

  • Page 11: Mechanical Specifications

    GDE060BAFL-T 7 Mechanical Specifications 7.1 Dimension VALUE UNIT Remark PARAMETER Display Resolution dots 600×800 Active Area Dimensions Horizontal 90.6 Vertical 122.4 Screen Size Inch 6.0（ 3:4 diagonal） Pixel Pitch Horizontal 0.151 Vertical 0.153 Pixel Configuration Rectangle Overall Dimensions Width 101.8 Height 138.4...
  • Page 12 GDE060BAFL-T...

  • Page 13: Optical Characteristics

    GDE060BAFL-T 8. Optical Characteristics Values Parameter Conditions Units Notes Min. Typ. White Reflectivity 0 minute Contrast Ratio (CR) 2 minute 1500 1600 GC16(T=0℃) 1200 GC16(T=25℃) Image Update Time: GC16(T≥35℃) DU (T=0℃) DU(T≥20℃) =25℃, f =50Hz. Measurements are made with Eye-One Pro Spectrophotometer.) Notes: 1.

  • Page 14: Handling, Safety And Environment Requirements

    GDE060BAFL-T 9. Handling, Safety and Environment Requirements Warning The display glass may break when it is dropped or bumped on a hard surface. Handle with care. Should the display break, do not touch the electrophoretic material. In case of contact with electrophoretic material, wash with water and soap.

  • Page 15: Reliability Test

    GDE060BAFL-T 10. Reliability Test TEST CONDITION METHOD REMARK At the end of the test, electrical, High- T = +50°C, RH = 30% for IEC 60 mechanical, and optical Temperature 168 hrs 068-2-2Bp specifications shall be satisfied. Operation Low- At the end of the test, electrical,...

  • Page 16: Block Diagram

    GDE060BAFL-T 10. Reliability Test TEST CONDITION METHOD REMARK At the end of the test, electrical, High- T = +50°C, RH = 30% for IEC 60 mechanical, and optical Temperature 168 hrs 068-2-2Bp specifications shall be satisfied. Operation Low- At the end of the test, electrical,...

  • Page 17: Packaging

    GDE060BAFL-T 12. Packaging www.e-paper-display.com 6.0 inch Series...
