2X72 GRINDER ASSEMBLY
INSTRUCTIONS
BRODBECK IRONWORKS LLC
REVISION R
1

Advertisement

Table of Contents
loading

Related Manuals for BRODBECK IRONWORKS 2X72

Summary of Contents for BRODBECK IRONWORKS 2X72

  • Page 1 2X72 GRINDER ASSEMBLY INSTRUCTIONS BRODBECK IRONWORKS LLC REVISION R...

  • Page 2: Table Of Contents

    Contents Main Chassis Assembly ......................9 Step 1 – Hinge and Hinge Base RH ..................9 Step 2 – X Brace ....................... 10 Step 3 – Hinge Base LH..................... 11 STEP 4 – Hinge Side Plate ....................12 STEP 5 – Tool Arm Plates ....................13 STEP 6 –...
  • Page 3 Lockout and secure power source before performing any work on the machine. Make sure to use adequate personal protection equipment such as eye protection, respirator, etc. while operating this equipment. Contact Brodbeck Ironworks LLC for any questions or concerns before operating this equipment Ben Secrist 513-532-7062,...
  • Page 4 Parts List: ITEM DESCRIPTION IMAGE HINGE BASE RH 2X72 HINGE BASE LH 2X72 FORMED HINGE 2X72 ½” CARRIAGE BOLT 1- 1/4”LG ½” THIN NYLOCK NUT ½” TEFLON WASHER .020” THK...
  • Page 5 BLACK ADJUSTABLE HANDLE ½”-13 INTERNAL THREAD 5/16” X 3/4”LG SCREW 5/16” THIN LOCK NUT ½” FLAT SAE WASHER 1/4” FLAT WASHER GRAY ADJUSTABLE HANDLE 3/8”-16 EXTERNAL THREAD 3/8" HEX BOLT 5/8” LG HINGE-SIDE SIDE PLATE...
  • Page 6 TOOL ARM TOP PLATE TOOL ARM PLATE 5/16” CARRIAGE BOLT 2-1/2” LG MOTOR MOUNT SIDE PLATE 5/16” SPACER 1/2" ID 1.0”OD ½” CARRIAGE BOLT 1- 3/4”LG TRACKING/TENSIONING ASSEMBLY...
  • Page 7 GAS SPRING (20LB) GAS SPRING EYELET 5/16” HEX BOLT 1” LONG 3/8” THREADED TAPERED HANDLE LOBED TRACKING KNOB 3/8” THREADED 4” TRACKING WHEEL MOTOR 3/8” HEX BOLT 1” LONG 3/8” SPLIT LOCK WASHER...
  • Page 8 5” DRIVE WHEEL ¼” SET SCREW ½” LONG **Hardware for the Mareko Standard Platen are included in the chassis hardware kit. Refer to the Mareko Platen or Standard Platen instructions for the assembly process.

  • Page 9: Main Chassis Assembly

    Main Chassis Assembly Step 1 – Hinge and Hinge Base RH Insert a 1/2" x 1-1/4" long carriage bolt into the top hole of the Hinge Base. Then add a 1/2" teflon washer (.020" thick) to the bolt. Add the hinge on top of the carriage bolt. Then add a 1/2"...

  • Page 10: Step 2 - X Brace

    Step 2 – X Brace Insert X-Brace into the Hinge Base. Slide 5/16-18 nylock nuts into the X-Brace. Secure with 5/16-18 x 3/4” long Button Head Screw by inserting it through the Hinge Base into the nylock nut.

  • Page 11: Step 3 - Hinge Base Lh

    Step 3 – Hinge Base LH Insert a 1/2" x 1-1/4" long carriage bolt into the top and bottom hole of the Hinge Base. Then add a 1/2" teflon washer (.020" thick) to the top bolt. Install the Hing Base onto the X-Brace and Hinge.

  • Page 12: Step 4 - Hinge Side Plate

    STEP 4 – Hinge Side Plate Install the 3/8-16 Threaded Handles into the Hinge-Side Side Plate. Do not tighten down all the way. Only tighten until the tip of the threads meet the inside face. Lower the hinge-side side plate onto the hinges. Use two 3/8-16 x 5/8” Long hex head bolts.

  • Page 13: Step 5 - Tool Arm Plates

    STEP 5 – Tool Arm Plates Install the tabs of (in order from front to back) the tool arm top plate and tool arm plates (3), into the slots of the hinge-side side plate.

  • Page 14: Step 6 - Motor Mount Side Plate

    STEP 6 – Motor Mount Side Plate Place the motor mount side plate onto the tool arm and tool arm top plates. Insert (4) 5/16-18 x 2-1/2” carriage bolts and secure with the 5/16 nylock nuts. If you overtighten the sides plates may bow outward.

  • Page 15: Step 7 - Tension Arm

    STEP 7 – Tension Arm Install the tension arm using the ½-13 x 1.75” carriage bolt, spacer, flat washer(s), and nylock nut. Tighten enough to eliminate side to side wobble. Overtightening can cause tracking issues. Additional washers are provided to fine tune the tracking.

  • Page 16: Step 8 - Gas Spring

    STEP 8 – Gas Spring Install the gas spring using 5/16-18 x 1.00” hex bolt, a flat washer on both sides of each eye, and nylock nut. Do not overtighten the gas spring bolts. It will bind and cause tracking issues and premature failure.

  • Page 17: Step 9 - Tracking Knob And Handle

    STEP 9 – Tracking Knob and Handle Insert 3/8-16 threaded handle into the tension arm (apply loctite). Install 3/8-16 threaded knob into the tension arm. This will be used to adjust tracking in operation. STEP 10 – Tracking Wheel Install the tracking wheel into the tracking arm using ½-13 x 3” hex bolt, nylock nut, and flat washer.

  • Page 18: Step 11 - Motor Install

    STEP 11 - Motor Install Tilt the chassis into the horizontal position. Install motor into belt side plate using 3/8-16 x 1 hex bolts and split lock washers. Make sure the feet of the motor are facing the rear of the machine.

  • Page 19: Step 12 - Drive Wheel Install

    STEP 12 - Drive Wheel Install Install drive wheel and secure with set screw. Align with other wheels to ensure proper tracking. The drive wheel should be approximately 7/16” off of the side plate.
  • Page 20 Additional Notes: - Make sure all wheel centerlines are aligned with each other to ensure proper tracking. There may be some variance due to tolerance stack ups. - To make sure the belt has enough tension, put the belt on all four wheels, pull and hold down the tension arm all the way, pull the platen arm out until the belt is tight, lock the platen arm in place, and release the tension arm.

  • Page 21: Wiring Instructions

    Wiring Instructions Below is a reference aid for the electrical wiring for your grinder. Please make sure your set up matches the manufacturers instruction supplied. WARNING: HIGH VOLTAGE. DISCONNECT ALL POWER BEFORE ANY ELECTRICAL WORK Variable Speed Motor Wiring Open junction box and connect the 4 conductor cable as follows: 1.
  • Page 22 3. Connect T1 and T7 to the 4 conductor cable black wire. 4. Connect T3 and T9 to the 4 conductor cable white wire. 5. Connect T2 and T8 to the 4 conductor cable red wire. **NOTE: There are two wires(P1 & P2) that smaller than the others. These are not used. They can be left alone.

  • Page 23: Vfd Setup

    VFD Setup 1. Install cord grips and wire 4 conductor cable (coming from motor). Strip 4-6” of cable jacket and separate each wire. Strip and install supplied ferrules and y connector(ground). Install according to the diagram as shown in “A” below. If the motor runs backwards, switch the red and white wires.
