Think Appliances GCE7000 User Manual

70 cm knob control 4 zone ceramic cooktop
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual for your
GCE7000
70 cm Knob control
4 zone ceramic cooktop
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not fami
liar with the o
peration of the appliance.
JW 17/09/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GCE7000 and is the answer not in the manual?

Questions and answers

Related Manuals for Think Appliances GCE7000

Summary of Contents for Think Appliances GCE7000

  • Page 1 User Manual for your GCE7000 70 cm Knob control 4 zone ceramic cooktop NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...

  • Page 2: Table Of Contents

    Contents Environmental note Important safety information 3 – 5 Specifications 6 – 7 Product and aperture dimensions Product specifications lectrical details Ceramic cooktop surface layout Using the ceramic cooktop 8 - 10 Before first use Touch controls Switching on a cooking zone and setting a power level esidual heat indicator Cooktop guidelines 9-10...

  • Page 3: Environmental Note

    nvironmental note o The packaging materials that the manufacturer uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment.

  • Page 4: Important Safety Information

    Important safety information Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure o f any of the information contained in this booklet, please contact...
  • Page 5 Child Safety The manufacturer strongly recommends that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. During and after use, all surfaces will become hot. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
  • Page 6 leaning o Cleaning of the cooktop should be carried out on a reg ular basis. o IMPORTANT: Before attempting to clean the appliance, it should be disconnected from the mains an d allowed to cool. o Great care should be taken whilst using this appliance and when following the cleaning procedure.

  • Page 7: Specifications

    Specifications Product dimensions Aperture dimensions Depth: 520 mm Depth: 485 mm Width: 700 mm Width: 560 mm Height: 46 mm Product specifications: o 2 x 1.80 kW radiant zones (Ø 180 m 2 x 1.20 kW radiant zones (Ø 145 m o Knob control op eration o 4 individual resid...

  • Page 8: Electrical Details

    Electrical details Rated Voltage: 220-240 Vac 50-60 Hz Supply Connection: 30A (do uble pole switched fused outlet with 3mm contact gap) ax Rated Inputs: 6.0 kW ains Supply Lead: 3 core x 6 mm² (not supplied) For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice.

  • Page 9: Using The Ceramic Cooktop

    Using the ceram ic cooktop Before first use IMPORTANT: You should clean the ceramic cooktop surface (see “Cleaning and maintenance” section). o You should switch on one cooking zone at a time, for 5 minutes at the maximum setting. This will help to eliminate any new smell that exists and evaporate any humidity that has formed on the heating elements during transit.

  • Page 10: Residual Heat Indicator

    Residual heat indicator The residual heat indicator is located above the control knobs. o After a zone is switched off, the corresponding cooking zone residual heat indicator will il luminate. This means that the temperature of the zone is over 50°C and is therefore still high enough to cause injury.

  • Page 11: Cleaning And Maintenance

    o If these rules are not followed, then there will be a great loss of heat and energy. Heat not absorbed by the saucepan, will spread to the cooktop, frame and surrounding cabinets. o Preferably cover pans with a lid to permit cooking at a lower heat. o Always cook vegetables and potatoes, etc.

  • Page 12: Cleaning Table

    Cleaning table Type of deposit Remove Remove when What should I Immediately? the appliance use to remove has cooled the deposit? down? Sugar or Ceramic food/liquid cooktop scraper containing sugar Tin foil or plastic Ceramic cooktop scraper Fat splashes Ceramic cooktop cleaner Metallic Ceramic...

  • Page 13: Installation

    Installation The installation must be carried out by a suitably qualified person, in accordance with the current version of the following. o AS/NZS 3000: 2007 Wiring Regulations o 2010 Electricity Safety Regulations Positioning The adjacent furniture must be able to withstand a minimum temperature rise of 85°C above the ambient temperature of the room it is located in, during periods of use.

  • Page 14: Installing The Appliance

    Installing the appliance o Cut a hole in the worktop that corresponds with the relevant drawing shown above. o IMPORTANT: You must observe the ventilation requirements shown in the drawing above.
  • Page 15 o IMPORTANT: There are ventilation holes around the outside of the cooktop. YOU MUST ensure that these holes are not blocked by the work top, when you put the cooktop into position (see drawing opposite). o NOTE: Your appliance comes fitted with a sealing strip already attached to the underside of the cooktop.

  • Page 16: Electrical Connection

    Electrical connection This appliance must be installed by a qualified person in accordance with the latest edition of the Regulations currently in force and in compliance with the manufacturer’s instructions. o AS/NZS 3000: 2007 Wiring Regulations o 2010 Electricity Safety Regulations Before connecting the appliance, make sure that the supply voltage marked on the rating plate corresponds with your mains supply voltage.

  • Page 17: Replacing The Mains Supply Cable

    o The cable connections must be in accordance with the diagram located on the bottom of the cooktop (see previous page). The links must also be positioned as indicated. o You should use a good quality screwdriver to carefully, fully tighten ALL of the terminal screws.

  • Page 18: My Appliance Isn't Working Correctly

    My appliance isn’t working correctly o The cooking zones are not functioning or will not switch on. * Check that the mains electrical supply to the appliance is correct and working. Check the mains fuse. o The residual heat indicator has not come on after I have switched a cooking zone off.
  • Page 19 IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact Customer Care. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if a service technician is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.

  • Page 20: C Ontact Details

    Think Appliances Pty Ltd. 416-424 Barry Rd Coolaroo VIC 3048 Sales Telephone 1300 132 824 Service Telephone 1800 444 357 Website www.thinkappliances.com...
