Eagleye IS-CV200SIG40 Quick Start Manual

Specification

Model
IS-CV200SIG40
Pick up Element 1/2.8" SONY 2.4MP CMOS Sensor
Effective Picture
1920 X1080
Elements (H×V)
Resolution 1080P
0.001 Lux/F1.2
Minimum Illumination
S/N Ratio More than 50dB
Synchronous System Internal, Negative sync.
40 Meters (with Ф5X42PCS Infrared LED)
IR Distance
IR Power On Photodiode AUTO Control
CVI
Video Output
Functions DNR,UTC
Power/Current
DC12V(+/-10%)/700mA
Lens 2.8-12mm Manual Zoom Lens
IP Rating IP66
Dimension (mm)
291(W) x 90(H) x 93(D)
Weight (g) 1600
Operating Tempera-
-10~+50℃ RH95% MAX
ture

Accessories list

Name
Camera
User Guide
Notes:
Number
Do not attempt to disassemble the camera. If the camera
1
can not work, please contact local franchiser or our company.
1
CCTV Camera
Weatherproof IR Camera
Thank you for using our product.
Before providing power for the camera, please read
this manual carefully before use.
We adopt the latest technical of sensor and driver.
It owns the characters of high definition and stability,
strong anti-jamming, rich and real color. Fixing and
using this model are convenient too. It is very good
for you to apply to your CCTV system.
