Summary of Contents for Iceco PB250WH
- Page 1 Manual www.icecofreezer.com official@icecofreezer.com...
-
Page 3: Table Of Contents
DIRECTORY 1. Get to know your PB250WH 2. List of parts 3. Technical Specifications 4. Charging 5. Announcements 6. Frequently Asked Questions (FAQs) 7. Troubleshooting 8. Service life of lithium ion batteries 9. Disposal... - Page 4 CHARGE FIRST! Before reading through the manual, you can begin to charge up your PB250WH by connecting it to the power supply provided and plugging it in at the wall. Noncompliance with the safety instructions may cause injuries due to...
-
Page 5: Get To Know Your Pb250Wh
Instruction Manual | PB250WH Undead Car Charger Get to know your PB250WH DC Output port Type-C port 13.3V car cigarette port USB ports (4x) ON/OFF button ON/OFF button Digital Indicator DC Input port Remarks: Press the button to turn on all the outputs. -
Page 6: List Of Parts
Instruction Manual | PB250WH Undead Car Charger List of parts Item Quantity PB250WH Undead Car Charger Instruction manual and warranty AC Wall Charger Carry bag Type-C Output cable DC Cigarette Lighter Plug Cable Manual www.icecofreezer.com o cial@icecofreezer.com Remarks: We strongly recommend using our kitting of standard... -
Page 7: Technical Specifications
Instruction Manual | PB250WH Undead Car Charger How to use the nonstandard power inverter to charge laptop Step 1: Plug the external inverter into the car cigarette port. Step 2: Press the power button. Step 3: Plug the laptop AC adapter into the outlet of the inverter. -
Page 8: Charging
Instruction Manual | PB250WH Undead Car Charger Ports INPUT 12V-30V,100W MAX Car Cigarette Output 13.3V,10A max 6mm DC Output 12V, 3A Type-C Output 5V,3A max USB Output (4X) 5V, 2.4A (4.8A max) General Net Weight 4.10 lb (1.86 kg) 245 x 195 x 130 m Dimensions (9.6 ×... - Page 9 Using the AC wall charger provided, plug your PB250WH into any wall outlet. When the digital indicator displays 100, PB250WH is fully charged. It will be fully charged in 7 hr with charging stops when full of energy. LAPTOP The AC wall charger comes in two pieces.
-
Page 10: Announcements
Instruction Manual | PB250WH Undead Car Charger Announcements 5.1. How to use PB250WH Press the power button to turn on your PB250WH, then the digital indicator will display. Plug in your device for mobile power. You’ll know if it’s powering devices when the numbers of digital indicator change. - Page 11 5.3. Storage and Downtime Maintenance Please charge your PB250WH fully before storage and fully recharge your PB250WH every 3 months and store it in a cool, dry place.The storage temperatures range from -20°C to 45°C. If the system shuts down automatically because of lower battery capacity, please recharge it.
-
Page 12: Frequently Asked Questions (Faqs)
When lit up, you’ll see the numbers of remaining capacity change. You can turn on the battery display by push the power button. It is ok to use your PB250WH even when it’s not fully charged. How do I know if my device will work with the PB250WH? First, you’ll need to determine the amount of power your device... -
Page 13: Troubleshooting
2.Check the Battery Display. If it is at 20% or below, recharge your PB250WH. 3.Verify your device is suitable for use with the PB250WH. a. All of the PB250WH output ports have their own max power. Check the PB250WH technical specifications to ensure your device is compatible. -
Page 14: Service Life Of Lithium Ion Batteries
Instruction Manual | PB250WH Undead Car Charger Service life of lithium ion batteries Charge, supply current and store between -20 and 45°C. Using the battery at temperatures outside the lower and upper limits reduces the battery‘s running time. Do not expose to water or rain. -
Page 15: Disposal
Instruction Manual | PB250WH Undead Car Charger Fully charge the battery prior to placing it in storage. Fully charge the power supply unit prior to lengthy periods of non-use for storage and recharge the unit at least once a year. - Page 16 Dear valued customer, Welcome to the ICECO community! We are here to assist you on every step of your journey with us. Feel free to contact our after-sales team for any questions or concerns. We will do our best to solve your issue and make this a better experience for you.
