- Page 1 Telecom Test PDA User Manual V6-1.0...
- Page 3 Brief Introduction Thank you for purchasing our telecom test PDA. This user manual includes function introduction, installation, wiring, operation process, and problems solution. Please read the manual carefully before use, and keep it in safe and convenient place so that you can quickly find it when problems occur.
- Page 4 It is strictly forbidden to copy or reproduce all or part of this manual without the written permission of the company.
-
Page 5: Table Of Contents
Contents Chapter I Product Overview ..........1 1. Introduction ............... 1 2. Function List ............. 2 3. Components and Functions ........4 4. Main Features ............7 Chapter II Technical Specifications and Basic Functions . 8 1. Technical Specifications ..........8 1.1 Optical Power Index ......... - Page 6 2.3 Network Card..........12 2.4 PPPOE Dial ............ 13 Chapter III Usage of Main Functions ......... 14 1. Optical Power Test ............ 15 2. Visual Fault Locator ..........19 3. Gigabit Speed Test ........... 20 4. 5G WIFI Speed Test ..........21 5.
-
Page 7: Chapter I Product Overview
Chapter I Product Overview 1. Introduction The telecom test PDA is based on Android smart phone platform, which is a handheld multi-functional testing device design for telecom operator for LAN test, optical power test, red light source, gigabit speed test, 5G WIFI speed test, and TV functions. -
Page 8: Function List
2. Function List Function Module Module Classification Remarks Module Code With 1D barcode scanning Barcode Optional module Optical power with 1625nm Optical power Choose one meter Optical power with 1577nm Red light source IPTV With IPTV module Gigabit speed With Gigabit speed module 5G WIFI With 5G WIFI speed test HDMI... - Page 9 Back jacket With back clip port Optional 2 million pixels Optional Front camera 5 million pixels Optional 8 million pixels Optional 8 million pixels Optional Rear camera 13 million pixels Optional 16 million pixels Optional Battery 6000mAh capacity 2+16 RAM 2G, ROM 16G Memory Choose 3+32...
-
Page 10: Components And Functions
3. Components and Functions... - Page 12 Code Name Function Telephone receiver Telephone receiver Front camera Take photo or video Display Screen display Rear camera Take photo or video LED light LED light also can be used as flashlight Menu Key Menu key Home Key Home key Return key Return key Loudspeaker...
-
Page 13: Main Features
Device MIC HDMI port Video source tester input port Earphone hole Connect earphone Card port Placing a SIM card and a TF card Adjust volume of phone call or the loud Volume key speaker Power key Power on/off 4. Main Features ➢... -
Page 14: Chapter Ii Technical Specifications And Basic Functions
➢ Rechargeable 3.8V 6000mAh polymer battery ➢ Support 802.11a/b/g/n/ac, WIFI 2.4G and 5G ➢ Support Bluetooth function ➢ Support flashlight function ➢ Volume: 167 * 87 * 25mm (without scanner) ➢ Weight: 400g Chapter II Technical Specifications and Basic Functions 1. -
Page 15: Visual Fault Locator Index
⚫ Display distinguishability Linear display: 0.1% Logarithmic display: 0.01 dBm ⚫ Universal interface 1.2 Visual Fault Locator Index ⚫ Laser: FP-LD ⚫ Wavelength: 650nm±20nm ⚫ Output power: 1mw/3mw/5mw/10mw (You can choose the different power value) ⚫ Connector: universal ⚫ Working mode: CW or 2Hz modulation ⚫... -
Page 16: Hdmi
2) Network configuration: ➢ Support DHCP, PPPOE and static IP Internet connection ➢ Can set the download thread count ➢ Can set testing time ➢ Can set testing URL address 1.4 HDMI 1) Interface Support HDMI protocol interface 2) Resolution Support 4K, HD1080P, HD1080I, HD720P, SD480P, VGA, Auto and other resolutions 1.5 5G WIFI... -
Page 17: Basic Functions
➢ Can set the download thread count ➢ Can set testing time ➢ Can set testing address 2. Basic Functions 2.1 OTG USB Function Through USB OTG data line can connect PDA to USB, transfer files and data backup. The PDA support USB storage device including U dish, reader and phones which support large capacity USB storage function. -
Page 18: Network Card
2.3 Network Card To open the device's network card, pull down the prompt bar and click the LAN icon . Long pressing LAN icon can open. You can choose DHCP or STATIC from Ethernet IP mode. Under DHCP mode, click again to get IP address from DHCP server. -
Page 19: Pppoe Dial
2.4 PPPOE Dial To make PPPOE dial, you need to pull down prompt bar and click LAN to open network card, and long pressing PPPOE icon , the PPPOE window pop up. Input user name and password, click “Connect” to establish PPPOE link. Please see the following pictures:... -
Page 20: Chapter Iii Usage Of Main Functions
Chapter III Usage of Main Functions Swipe up the standby screen, showing main menu, as below: Swipe up or down to see all menu items. Press the back key to close the main menu. Drag the user's favorite functions onto... -
Page 21: Optical Power Test
the desktop: press and hold the icon to be moved, drag the icon to the position where you want to place. (During moving, keep pressing the icon and do not release) 1. Optical Power Test Optical power test can test the power of optic fiber signal, insert the pigtail of optical signal to be tested into the optical interface can test optical power, interface as below:... - Page 22 The six wavelengths on screen is calibration wavelength, choose corresponding wavelength can test current optical power value. The test value will be shown in the unit of dBm and nW meantime. User can stop testing by pressing "Stop Test", and displayed the latest test result. Click “Save” key to save the current test result.
- Page 23 Click “Insp” button can create inspection mission for line inspection operation, as shown below: Input the name of the line to distinguish different lines. Inspection significance: test different positions optical power value in one fiber, then draw the power curve (similar to the OTDR's test curve), you can view any attenuation values between 2 points.
- Page 24 After establishing inspection mission, click on the inspection button, current optical power value will be added to the inspection record end and will be displayed by the curve graph. The two vertical lines are two movable cursors; drag the cursor to view the power value and difference of any two points.
-
Page 25: Visual Fault Locator
2. Visual Fault Locator The device has red light source output, which can output continuous red light or 2Hz modulated light. Click the red light source, the device enters the red light source interface, as shown below:... -
Page 26: Gigabit Speed Test
Click "Open" to turn on the VFL, and click "Close" to turn off the VFL. CW/2Hz is the switch button of the continuous and modulated light, the tester can memorize the VFL mode automatically. The output power is 1mw/3mw/5mw/10mw (optional). 3. -
Page 27: G Wifi Speed Test
4. 5G WIFI Speed Test 1. Module Initialization Instructions for use: In settings, open "MIMO WLAN" option under "Network and Internet", and then connect to WIFI。 2. Start to Test Instructions for use: In the speed test interface, set the test IP address and the number of threads, then click "Start"... -
Page 28: Operation Method
5.2 Operation method Open the TV set-top box, turn on the TV function on the device, and use the HDMI cable to connect the TV set-top box and the device. After the device automatically recognizes and analyzes the resolution of the video source, it will automatically play the audio and video. -
Page 29: Barcode Scan Function (Optional)
6. Barcode Scan Function (Optional) Provide SDK, can do secondary development. 7. SIM Card (Optional) Support ISO7816 Agreement, provide SDK, secondary development. 8. How to Install the USB Driver Connect the device and PC with USB data line, pull down the prompt bar and showing the USB connect state, click File Transfer, for the first time connect PC, there will installation window appears:... -
Page 30: Chapter Iv Simple Troubleshooting
Chapter IV Simple Troubleshooting If there is a problem with your device, please see the following "Troubleshooting Methods" firstly carry corresponding operation. If the problem is not resolved, please contact professional service personnel. Problem Possible Causes Troubleshooting Method Press power key Press the power key more not enough than 2 seconds... - Page 31 records Degraded battery Change battery performance Insufficient standby time Long time games Restrict games and music and music play play time Check connection, replace Poor connection socket or plug Will cause no charge display, Battery voltage is charge half hour firstly, then too low unplug and then recharge Charging failed...
- Page 32 interference install it after 1 minute Check or exchange device Device card failed card Cannot call Reach to cost limit Contact operator Phone number Check the number over digits Partial calls cannot call Check if set the calling Setting issues restriction Incorrect PIN error...
