M881N-SICR-YYVM
1
Insert Column
Assembly
2
YOU WILL RECEIVE
Wheel
without Lock
X2
Spacer
X1
Ensure the protruding metal fits completely into the
groove (Use a soft-faced hammer where necessary).
A tight fit will ensure the tabletop stays SECURE.
Table Top (Small)
Remove the triangle knob and spacer from the draw pipe.
Then insert draw pipe completely.
Page 1
Wheel
Triangle
Bolts
with Lock
Knob
X2
X2
X1
Chrome
Dust
Plate
Screw
Cap
x1
x1
x1
Lay Table Tops on Flat Surface
Ref no: M881N-SICR-YYVM Manual V7022321
YOU WILL NEED
Phillips
Wrench or 5/8"
Screwdriver
Box End Wrench
Table Top (Large)
