S
SCP-PCU796-010-04H
ECTION
PG-P
LUS
T
P
ECHNICAL
PGTC Conditioner Unit
Model
List
CLEI Code
PCU-796
1
S9TPLKNB~~
RACTICE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PG-PLUS PCU-796 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADC PG-PLUS PCU-796

  • Page 1 PG-P ECHNICAL RACTICE PGTC Conditioner Unit Model List CLEI Code PCU-796 S9TPLKNB~~ SCP-PCU796-010-04H ECTION...
  • Page 2 Information furnished by ADC is believed to be accurate and reliable. In no event shall ADC be liable for any damages resulting from the loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
  • Page 3 • Unpack each container and visually inspect the contents for signs of damage. If the equipment has been damaged in transit, immediately report the extent of damage to the transportation company and to ADC. Order replacement equipment, if necessary. •...
  • Page 4 Inspecting Your Shipment SCP-PCU796-010-04H June 24, 2003 PCU-796 List 1...
  • Page 5: Table Of Contents

    SCP-PCU796-010-04H ABLE OF ONTENTS Product Overview_____________________________________________________________________ 1 Theory of Operation...........................1 Description and Features........................3 PGTC Conditioner Unit.......................3 PCU-796 List 1 ........................4 LED Descriptions..........................6 Card-Edge Connector.........................7 Installation............................8 PCU-796 States ..........................8 Active State..........................8 Inactive State ........................8 Servicing ..........................8 Product Support ______________________________________________________________________ 9 Technical Support ..........................9 Limited Warranty..........................9 Returns ...............................9 FCC Class B Compliance ........................11...
  • Page 6 SCP-PCU796-010-04H June 24, 2003 PCU-796 List 1...
  • Page 7 SCP-PCU796-010-04H IST OF IGURES 1. PGTC Block Diagram .............................1 2. Non-Integrated MLT-2............................2 3. Integrated MLT-2 Using PCU-796 .........................3 4. PCU-796 Unit..............................6 5. Installing the PCU-796 into an HUS-340 Shelf ....................8 PCU-796 List 1 June 24, 2003...
  • Page 8 SCP-PCU796-010-04H June 24, 2003 PCU-796 List 1...
  • Page 9 SCP-PCU796-010-04H IST OF ABLES 1. LED Indicators on Front Edge of the PCU-796 ....................6 2. Edge Connector Pinouts ..........................7 PCU-796 List 1 June 24, 2003...
  • Page 10 SCP-PCU796-010-04H June 24, 2003 PCU-796 List 1...
  • Page 11: Product Overview

    SCP-PCU796-010-04H Theory of Operation RODUCT VERVIEW This practice describes the PCU-796 List 1, a pair gain test controller (PGTC) Conditioner Unit (PCU), that provides control signals from the PGTC to I-MLT-2 during Mechanized Loop Testing (Integrated MLT) (see Figure 1). HEORY OF PERATION To complete MLT testing on a PG-Plus...
  • Page 12 Theory of Operation SCP-PCU796-010-04H The PCU-796 is not required in Central Offices (CO) that use Nonintegrated MLT-2 systems. Figure 2 shows the typical connections of Nonintegrated MLT-2. In this case, the Sleeve lead passes through the PGTC to the No Test Trunk in the switch.
  • Page 13: Description And Features

    SCP-PCU796-010-04H Description and Features The differences in the Integrated MLT-2 case are shown in Figure 3. Here the PCU-796 is necessary because a No Test Trunk is not present in this set-up. The PCU-796 monitors the unconnected Sleeve lead and responds with -48 V battery coupled through a resistor to the Trunk Ring lead when the MLT opens its Sleeve lead at the end of testing.
  • Page 14: Pcu-796 List 1

    Description and Features SCP-PCU796-010-04H PCU-796 List 1 The PCU-796 mounts in a single-width 400-type mechanics enclosure such as the Pair Gain HUS-340 HiGain Universal Shelf. A single PCU-796 has four separate conditioner circuits to handle all the ports on a single PGTC. When used in a HUS-340 shelf, up to three PCU-796 units can be accommodated.
  • Page 15 SCP-PCU796-010-04H Description and Features Specifications Function PGTC Four individual conditioner circuits. Used in I-MLT-2 applications with PG-Plus Material Glass-epoxy circuit board Finish Wet-film solder mask Dimensions Width 5.6 in. (14.2 cm.) Length 5.6 in. (14.2 cm.) Height 1.4 in. (3.6 cm.) Weight 0.6 lbs.
  • Page 16: Led Descriptions

    LED Descriptions SCP-PCU796-010-04H LED D ESCRIPTIONS Figure 4 shows the PCU-796 front edge indicators. One green POWER LED and four yellow CONDITIONER LEDs are present. The POWER LED is green when the -48 V office battery and battery return are present at the card edge pins.
  • Page 17: Card-Edge Connector

    SCP-PCU796-010-04H Card-Edge Connector ONNECTOR The PCU-796 connector has 56 gold-edge fingers that mate to a standard 400-type connector. Table 2 lists the PCU-796 card-edge connector pinouts. Although all the Trunk Tip connections are not used, they are shown for wiring convenience. Wire the trunk Tip #n (where n equals the Tip or Ring number), trunk Ring #n, and sleeve #n leads to the corresponding leads on the PCU-796 shelf.
  • Page 18: Installation

    Installation SCP-PCU796-010-04H NSTALLATION To install the PCU-796, slide the PCU-796 into the card guides of the slot that is wired for PGTC conditioning, then press on the metal insertion handle until the unit seats fully into its connector. Figure 5 shows installation into a HUS-340 shelf.
  • Page 19: Product Support

    ADC’s Return Material Authorization (RMA) Department. Call or write ADC’s RMA Department to ask for an RMA number and any additional instructions. Use the telephone number, fax number or email address listed below: •...
  • Page 20 Pack the equipment in a shipping carton. Write ADC’s address and the RMA Number you received from the RMA Department clearly on the outside of the carton. All shipments are to be returned prepaid. ADC will not accept any collect shipments.
  • Page 21: Fcc Classb Compliance

    The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by ADC voids the user's warranty. All wiring external to the product(s) should follow the provisions of the current edition of the National Electrical Code.
  • Page 22: Acronyms

    Modifications SCP-PCU796-010-04H CRONYMS Central Office Digital Loop Carrier HiGain Universal Shelf ISDN Integrated Services Digital Network Light Emitting Diode Mechanized loop Testing Pair Gain Conditioner Unit PGTC Pair Gain Test Controller Return Materials Authorization June 24, 2003 PCU-796 List 1...
  • Page 24 World Headquarters: ADC Telecommunications, Inc. PO Box 1101 Minneapolis, Minnesota USA 55440-1101 For Technical Assistance: 800.366.3891 ´,_^¶3¶¨ 1263623...
