Summary of Contents for Mobibooth Cruise Series
- Page 1 Quick Start Guide Mobibooth Cruise™ Version Date Author Comments 7-13-22 Initial release...
-
Page 2: Table Of Contents
Table of Contents Supported Devices ................4 Introduction ..................5 What’s in the Box ................6 Unpack and inspect the Cruise™ roamer ........7 Operator Controls ................. 8 Getting Started ................9 Installation of iPad charge cable ..........9 Installation of iPad ................. 9 1. - Page 3 5. Edit app modes ..............17 6. Customize LED Fx ..............18 7. Editing colors ................. 18 Manual Mode Usage ..............19 Selecting Attract Mode Pattern ..........19 Selecting Attract Mode Pattern ..........19 Manual White Light ..............20 Automatic Mode Usage ............. 20 Supported Fx Patterns ...............
-
Page 4: Supported Devices
Supported Devices iPad Models iPad Mini 3 iPad Mini 4 iPad Mini 5 IPad Air 2022 iPad Pro 10.5-inch iPad Pro 11-inch V e r s i o n 1 L a s t m o d i f i e d J u l y 1 3 , 2 0 2 2 P a g e... -
Page 5: Introduction
They’ve been purposefully built with ease of use and ergonomic comfort in mind. The Mobibooth Cruise™ can operate in two unique modes that include a decoupled manual mode, where the operator triggers the white light during photo taking, and fully automatic mode where the app can change the lights throughout the photo session automatically. -
Page 6: What's In The Box
What’s in the Box In addition to the Cruise roamer and carrying case you’ll find the following items in the box. The charge cable used to power the LEDs and optionally charge the iPad along with a backup. Two metal plates with adhesive backing. -
Page 7: Unpack And Inspect The Cruise™ Roamer
If you discover shipping damage upon inspection: • Immediately notify the shipping company and file a damage report. Mobibooth, LLC is not responsible for any damage to the roamer incurred during shipment, and will not cover the repair of this damage under its warranty policy. -
Page 8: Operator Controls
Operator Controls • Manual White Light Button - used to manually switch all LEDs to white. • Handle - used for holding the roamer. • 5VDC Input Plug - supplies power to the LEDs. • Manual Pattern Select Button - selects between 13 preprogrammed pattern/color combinations. -
Page 9: Getting Started
Getting Started This section outlines the steps required to set up the Cruise™ roamer for the first-time use. Installation of iPad charge cable This is an optional step that is only necessary if you decide to charge the iPad during operation. 1. -
Page 10: Locate Metal Plates
1. Locate metal plates Locate the two metal plates shipped with your Cruise™ roamer. 2. Prepare iPad Place the iPad backside up on a flat surface. V e r s i o n 1 L a s t m o d i f i e d J u l y 1 3 , 2 0 2 2 P a g e... -
Page 11: Metal Plate Installation
3. Metal plate installation Peel the paper back off of one metal plate and attach it to the center of the iPad. The Apple logo is a great reference. Peel the paper back off the second metal plate and attach it to the previously placed metal plate making a stack of two. -
Page 12: Remove Faceplate
4. Remove faceplate Remove the Cruise™ roamer faceplate. It is recommended that you firmly grip the faceplate through the iPad opening and the outside and lift steadily straight up. The magnetic lock will provide tension until the faceplate is 2 to 3 inches away from the body. -
Page 13: Install Ipad
6. Install iPad Place the iPad into the Cruise™ roamer. There are magnets that will secure the iPad using the newly attached metal plates. V e r s i o n 1 L a s t m o d i f i e d J u l y 1 3 , 2 0 2 2 P a g e... -
Page 14: Replace Faceplate
Recommended Battery Pack RAVPower’s 32000mAh Power Bank USB Battery Pack is the recommended battery pack for use with the Mobibooth Cruise™. With this unit it is possible to run as long as 8 hours between charges. The unit can be purchased at https://www.ravpower.com. -
Page 15: Bluetooth App Connectivity
To watch our video walkthrough demonstrating RGB LED integration and the Mobibooth Cloud™ app please visit https://youtu.be/ZLcw93qNcTs. 1. Open the Cloud app Open the Mobibooth Cloud™ by tapping the app icon on the iPad’s screen. 2. Log into your account Mobi Log into the app using your Mobibooth Cloud credentials. -
Page 16: Open Rgb Leds
These settings will be the default behavior for all events synced to the app. The Mobibooth Cloud app allows you to create custom LED Fx configurations for each event synced to the app. To access the... -
Page 17: Enable Connect To Bluetooth
4. Enable connect to Bluetooth This will cause the app to scan for a Mobibooth Bluetooth controller to connect to. Once connected the controller ID will be displayed below the word “connected”. 5. Edit app modes Once connected to the Bluetooth... -
Page 18: Customize Led Fx
6. Customize LED Fx There are currently 13 LED Fx patterns that are supported. Each can have a number of parameters customized including speed, delay and color. Tapping Preview will display the current settings without saving them. Tap Save to save parameter changes. -
Page 19: Manual Mode Usage
MANUAL MODE USAGE The Mobibooth Cruise™ roamer is capable of being used without app integration. When used in manual mode the roamer will display the selected LED fx pattern at the set brightness. The user can override this with a solid white for as long as they desire by pressing and holding the handle’s button. -
Page 20: Manual White Light
This should be used during photo or video capture. Automatic Mode Usage When used with app integration or in automatic mode the Mobibooth Cruise™ roamer will automatically change the LED fx pattern during the photo booth session as configured within the app. - Page 21 Blink 0-100 100-1000 Color Wipe 0-100 5-100 Cycling: true or false Double color wipe 0-100 5-100 Spin 0-100 5-100 1-50 Meteor Rain 0-100 5-100 1-50 Direction: cw or cww Fade In 0-100 5-100 Cyclone 0-100 5-100 1-50 Return delay: 0-5,000 (ms) Running Lights 0-100 5-100...
