Summary of Contents for ATD Tools ATD-7479
- Page 1 Model Number Capacity ATD-7479 1250 lbs. Model ATD-7479 (Gear box control rotating head) WARNING: This product may contain chemicals, including lead, known to the State of California to cause cancer, birth defects or other reproductive harm. Wash hands after handling.
-
Page 2: Product Description
6 thru 8). PRODUCT DESCRIPTION ATD Tools Folding Engine Stands are designed to safely support rated capacity engines. Welded steel tube construc- tion, heavy gauge steel head plates and mounting arms along with compliance with factory standards ensure safety, strength and stability. -
Page 3: Before Use
(#6) with M14x70 bolts, washers, spacers and nuts (#4, 3, 2 & 1). 8. Attach handle (#22) to gear box (#12) and secure with M5x12 bolt and spring washer (#14 & 15). Figure 3 - Assembly Illustration for model ATD-7479... - Page 4 Folding Instruction (refer to Figure 5) 1. Remove lock pin of center wheel assembly and slide it into the top hole and secure with cotter pin. 2. Remove cotter pins and lock pins from both legs. 3. Carefully and slowly fold the leg up. 4.
-
Page 5: Operation
Only attachments and/or adapters supplied by the freely. Apply very light coating of grease to head plate manufacturer shall be used. collar. If rust appears, sand affected area and cover with suitable utility paint. Parts Description List for model ATD-7479 Item Part# Qty. Item... -
Page 6: Replacement Parts
When ordering parts, give model number, part number and description. Call your distributor for current pricing: Parts Illustration for model ATD-7479 (refer to parts description on page 7) Post Head Assembly Figure 7 - Replacement Parts Illustration for model ATD-7479 Check out the collection of automotive lifts and stands we offer.
