OPERATING INSTRUCTIONS AND OWNERÊS MANUAL
READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the shower.
DANGER
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
– Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
– An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light appliance
• Extinguish any open flame
• Shut off gas to appliance
BATTERY OPERATED SHOWER SYSTEM
Fully Portable Instant Hot Water/Shower
CARBON MONOXIDE HAZARD
•This appliance can produce carbon monoxide which has
no odor
•Using it in an enclosed space can kill you.
•Never use this appliance in an enclosed space such as a
camper, car or home
Battery Operated Shower System
(Propane Cylinder Not Included)
Model #
XCW20
2015
Advertisement
Table of Contents
Related Manuals for Mr. Heater F235350
Summary of Contents for Mr. Heater F235350
- Page 1 OPERATING INSTRUCTIONS AND OWNERÊS MANUAL Model # BATTERY OPERATED SHOWER SYSTEM Fully Portable Instant Hot Water/Shower XCW20 READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has not read these instructions to assemble, light, adjust or operate the shower.
-
Page 2: Table Of Contents
WARNING: DANGER DANGER YOUR SAFETY IS IMPORTANT, SO PLEASE READ THESE INSTRUCTIONS EXPLOSION-FIRE BEFORE YOU OPERATE. HAZARD THIS MANUAL CONTAINS IMPORTANT INFORMATION ABOUT THE AS- Never store propane SEMBLY, OPERATION AND MAINTENANCE OF THIS PORTABLE SHOWER. near high heat, open flames, pilot lights, SAFETY PRECAUTIONS ARE ESSENTIAL WHEN ANY MECHANICAL OR direct sunlight, or other... -
Page 3: Shower Specifications
SPECIFICATIONS CAUTION: Certified for use only with LP-gas cylinders of the U.S. Department of Transportation (DOT) or Transport Canada, CAN/CSA B339. Model: XCW20 (F235350) 10,000 -18,000 Rating: BTU 5.0Ah Sealed Battery Lead Acid Internal Battery Run Time (Full Charge) 40 minutes... -
Page 4: Operating Precautions
Bubbles indicate a leak. Check that the connection is not cross threaded and that it is tight. Perform another leak check. If there is still a leak, remove the cylinder and contact Mr. Heater System On / Off Over- direct for service or repair. - Page 5 Position the Output Temp Control Dial to the central position. Swing the faucet away from its storage position and locate Depress the Pump button,the electronic ignition should be towards the side of the appliance and locate a basin or bucket heard igniting the burner.
-
Page 6: Maintenance, Storage And Service
APPLIANCE POWER & CHARGING The appliance is fitted with a 15V 5A/h battery pack and can be recharged with the AC or DC adaptors /supplied. FUSE DC INPUT AC INPUT Fig. 5 AC: Connect the 120V AC adapter to the appliance then con- nect the 3 pin AC plug to a suitable outlet (FIG. -
Page 7: Wiring Diagram
WIRING DIAGRAM CAUTION: Label all wires prior to disconnecting when servicing controls. Wiring errors can cause improper and dangerous operation. The parts lists and wiring diagram show the appliance as it was constructed. Do not use a heater which is different from that shown. -
Page 8: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION Check that pump debris filter is not clogged Check that appliance is switched on Check sufficient water is available Water will not flow from shower head Check that the pump is connected to the appliance Make sure the battery is charged Check for kinks in shower hose Check that pump fuse is not blown Check that the shower head ON/OFF switch is in the open position... -
Page 9: Exploded View
PARTS LIST MODEL: XCW20 Item # Description Part Number High Limit Switch 35526 Igniter 35548 Control, Charging Shower 35550 Switch, Tip over 35546 Ignition Electrode 35530 Ignition Electrode 35551 Switch, Flow, Water 35552 Handle Assembly 35545 Faucet(Faucet) Assembly 35553 Regulator Assembly 35534 Drain Plug 35536... - Page 10 Model # OPERATING INSTRUCTIONS XCW20 AND OWNER’S MANUAL WARNING: USE ONLY MANUFACTURERÊS REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH. REPLACEMENT PARTS ARE ONLY AVAILABLE DIRECT FROM THE FACTORY AND MUST BE INSTALLED BY A QUALIFIED SERVICE AGENCY.
