- Page 1 OPERATING MANUAL MODEL: SBT-2020/2025 www.digicon-systems.com USER MANUAL...
- Page 2 Thanks for Purchasing “THE BEST” Please read this document carefully to set and operate your device properly. In general, two settings are mandatory to operate the device in automatic mode. – Profile Setting. –Schedule Setting. Intel Your powered devices have too many advanced features, A brief features details are listed below! ❖...
-
Page 3: Home Screen
The detailed Setting of each and every step is given below! Please read carefully and keep this manual in safe place for future reference, a soft copy can be found on www.digicon-systems.com HOME SCREEN There are two operations are possible 1. -
Page 4: Time Setting
The details of each setting are given below! 1-TIME SETTING The time setting screen will look like this, please enter valid time hour and minute value in Indian time format (24-hour format). After successful setting, device will go back to setting mode menu, if further settings not needed, please press settings to go back to home screen. -
Page 5: System Setting
Here on password setting screen Use may change new system password, password should be a combination of four-digit numbers. After successful setting, the device will go back to setting mode menu. If further settings are not needed, please press settings to go back home screen. - Page 6 Each profile needs to set as per required time table, for example if we select Summer Profile to set! We have to press associated key number For the summer profile, key 1, the next screen will appear. The first line of this screen shows information, while the second line shows operational options, the most left two digit of the first line is serial number and ??:?? (Questioning marks) are space for time information in hour and minute.
- Page 7 WEEKLY SCHEDULE SETTING After selecting the first option, the device enters into “Weekly Schedule Setting” mode, Screen displays a message to select a weekly off day. Next screen appears shortly asking to select Weekly off day. The screen will display the short name of week’s day in the first line of display, while the respected day number will be displayed in the second line, please press key number for respected day to select weekly off day, after successful setting device will display a saved day for a while.
- Page 8 In the next screen device will ask to select desired month, to set or edit for holiday, User may start selecting January or current month. Please enter month number in two-digit format. For example, if user press “01” means January month, the next screen will appear and look like this. In this screen the first line indicated month name (JAN) and date (01) and next status of that date (USUAL DAY) means normal day.
- Page 9 SYMBOLIC CONNECTION DIAGRAM (Connection Diagram) Automatic power management of Audio Amplifier...
- Page 10 Caution: Risk of Electrical Shock! Device Should be Installed by Qualified Electrical Technician Only. Please don’t Keep the device on table during operative mode, Always Ask to your Technician to Install the Device on Wall. FACTORY RESET DEVICE. To soft reset the device for factory default configuration, please follow instructions mentioned bellow! 1.
- Page 11 There is no-meaning of serial number of files. So first short by name and copy them to SD card. 6. Mount Micro-SD card to the device. 7. Switch ON the power supply from Power ON-OFF Button. For further assistance: write us: mail@digicon-systems.com...
