Arcan ASC8013DLX Quick Start Manual

PARTS BREAKDOWN
REPlAcEmENT PARTS lIST
Item Part # # Req'd
1 *
2 RSSCPLW
3 RSSCPW
4 RSSCPP1
5 RSSCPHK
6 8011
7 8004
8 8002
* For replacement, purchase RSSC7, Chrome Leg, and 8014, Leg Extensions.
ASC8013DLX: Parts Breakdown & Operating Manual
INCLUDES PRY BAR HOLDER AND SIDE WORK BENCH
7
3
5
Description
2 Chrome Leg/ea.
2 Locking Caster/ea.
2 Non-Locking Caster/ea.
1 Set of 4 Plastic Inserts
1 Bolt Kit (Incl. 8 ea. of 10mm and 14mm
bolts, nuts, washers and 4 screws)
1 Pry Bar Holder
1 Side Work Station
1 Top Lid
MODEL ASC8013DLX
SERVICE CART WITH
LOCKING TOP & DRAWERS
1
8
4
AlSO AVAIlABlE
Part # Description
RS3HDL Short Drawer Handle
RS8006HDL Long Drawer Handle
RS8006HDLS Handle Screws (Set of 4)
RSRBSLIDEC2 Clip-On Roller Bearing Slide/pr.
8006 Replacement Large Drawer
8016 Replacement 3 Drawer Unit
8007 Replacement Third Shelf
8013LS 4-Piece Lock & Key Set, Keyed Alike
1110 EVA Foam for Trays / 10-pk.
1111 EVA Foam for Drawers / 10-pk.
8004SSM Rubber Liner for Side Shelf / 10-pk.
