Musictech MT 60 How To Set Up

HOW TO SET UP THE MT 60 CHROMATIC KEYBOARD

This MT 60 Chromatic Keyboard has very sensitive independent dynamic control on both Right and
Left Hands. The keyboards can be set up in several different configurations for both the Right and
Left hands as follows.
RIGHT HAND KEYBOARD (Chromatic) - MIDI TRANSMISSION on Channels 1 and 4
C Griff: C in first row
B Griff: C in second row
C in third row
LEFT HAND KEYBOARD (Bass and Chords)
- CHORDS MIDI TRANSMISSION on Channels 2 and 1 (can be added)
- BASS MIDI TRANSMISSION on Channel 3
In International, Belgian, Dutch or French system.
PRIMARY SWITCHING "ON" STAGES
The keyboard system programming stages are accessed when switching the instrument "On".
To enter the setup mode of the keyboard, two buttons are used:
- one on the chromatic Right Hand keyboard (button 1) - see Fig. 1.
- one on the Bass and Chords Left Hand keyboard (button 2) - see Fig. 2.
Hold these buttons down (shown by the arrows) while switching the instrument "On".
N.B. - Decide what setup you want for both Right and Left keyboards before beginning the
procedure below, because the useful time for each operation is just 3 seconds from when the first
two buttons are released.
The instrument, will confirm the programming done by sounding a note.

PROGRAMMING THE SYSTEM FOR THE RIGHT HAND KEYBOARD

After the primary switching "On" stages described in the previous paragraph, select the system
required by referring to Fig. 1 and following the instructions below.
To select C Griff (C in first row): press button A on Rt. Hand Keyboard.
To select B Griff (C in second row): press button B on Rt. Hand Keyboard.
(C in third row): press button C on Rt. Hand Keyboard.
RIGHT HAND DYNAMICS - The button dynamics on the Right Hand keyboard can be selected in
"On" or "Off" by referring to Fig. 1 and proceeding as follows:
Right Hand Dynamics active - press button D (Right Hand keyboard - chromatic).
Right Hand Dynamics not active - press button E (Right Hand keyboard - chromatic).
HOW TO SELECT THE OCTAVE OF THE NOTES ON THE RIGHT HAND (FOR ALL SYSTEMS)
The octave for the notes of the Right Hand keyboard can be set to a maximum of +/- 2 octaves by
pressing specific buttons listed below:
For Midi Channel 1:
Press button N on the keyboard (see Fig. 1 above) to lower the notes by 1 octave at a time.
Press button O on the keyboard to raise the notes by 1 octave at a time.
For Midi Channel 4:
Press button P on the keyboard (see Fig. 1 above) to lower the notes by 1 octave at a time.
Press button Q on the keyboard to raise the notes by 1 octave at a time.
