American Woodcrafters B2-233-26F Assembly Instructions

AMERICAN WOODCRAFTERS
1060E.SPRINGFIELD RD
HIGH POINT,NC 27263
(336)861-0003
Thank you for purchasing this quality product.Be sure to check all packing material carefully for small
parts,which may have come loose inside the carton during shipment.Identify and count all parts and
compare with the HARDWARE LIST below.
NO.

PARTS LIST

A
Linen fabric seat
B
Left leg
C
Right leg
D
Back leg
E
Front stretcher
Back stretcher
F

STEP 1

C
B
5
4
2
6
1.Loosely the attach the Left leg(B)and Right leg(C)
to the Linen fabric seat （ A ）， using Bolts
（ 2+4+5 ） to tighten ,as shown.
2.Loosely the attach the two (D)to the Linen fabric seat (A)
using Bolts （ 1+4+5 ） to tighten ,as shown.

STEP 3

3
PH Screwdriver
1.Loosely attach the Front stretcher(E) to the Left(B)
and Right Left(C),using Screw(3) to tighten,as shown.
Thank you for purchasing furniture from American Woodcrafters .If you have any issue.such as missing hardware,please contact the dealer
from which you made your purchase .They will be happy to help.Thank you for making American Woodcrafters part of your home.
ASSEMBLY INSTRUCTIONS
ITEM NO:B2-233-26F/B2-233-30F/B2-234-26F/B2-234-30F
Don't tighten any Bolts until all Bolts on a step have been started
PARTS NO.
B2-233/234-26FP1
B2-233/234-26FP2
B2-233/234-30FP2
B2-233/234-26FP3
B2-233/234-30FP3
B2-233/234-26FP4
B2-233/234-30FP4
B2-233/234-26FP5
B2-233/234-26FP6
D
1
6
A
E
NO. PARTS LIST
Q'TY
1
1
2
1
3
4
1
5
2
6
1
1

STEP 2

5
4
1.Loosely attach the Back Stretcher (F)
to the Back leg(D),using Bolts(1+4+5)
to tighten,as shown.

STEP 4

1.It's complete for using.
PARTS NO. Q'TY
1/4"*1-3/4"
1/4"*2-1/4"
#
8*1-3/4"
B2-233-26FP7
1/4"
1/4"*19mm
Allen wrench
F
6
4
4
10
10
1
