FOLDING STAIRWAY
Caterpillar 773D Truck
Installation and Mounting Instructions
NOTE
Follow all on-site/Mine lifting and safety procedures when installing
Power Step Landings to Truck.
PROCEDURE
See Drawing PS-22683
1. Remove existing cabin landing and cabin-side ladder.
2. Fit Mounting Bars per View 1. Do not tighten bolts.
3. Fit Top Landing, bolting to the tapped holes in the Mounting Bars.
4. Tighten all the bolts.
VIEW 1.
VIEW 2.
CAT 773D 19-12-12
Mounting Bars PS-22683
Pg3
