- Page 1 11 May 2019 FALCON ACCELERATION CARDS R80.20 Getting Started Guide...
- Page 2 Check Point. While every precaution has been taken in the preparation of this book, Check Point assumes no responsibility for errors or omissions. This publication and features described herein are subject to change without notice.
-
Page 3: Important Information
Certifications For third party independent certification of Check Point products, see the Check Point Certifications page https://www.checkpoint.com/products-solutions/certified-check-point-solutions/. Check Point R80.20 for Falcon Acceleration Cards For more about this release, see sk116242 http://supportcontent.checkpoint.com/solutions?id=sk116242. -
Page 4: Table Of Contents
Contents Important Information ....................3 Introduction ........................5 Supported Falcon Acceleration Cards and Security Appliances ........5 Falcon Acceleration Cards .................... 8 CPAC-Falcon-10G-B ....................9 CPAC-Falcon-40G-B ....................10 Installing Falcon Acceleration Cards ................11 Removing Falcon Acceleration Cards ................. 12 Configuring the Appliance ................... -
Page 5: Introduction
Introduction Introduction The Check Point Falcon Acceleration Cards provide a high performance, low-latency, flexible and scalable solution for Check Point 5900, 6800, 15000, and 23000 appliances. Falcon Acceleration Card is a dedicated network I/O card solution with an integrated Network Processor, which supports multiple connectivity options at 10 GbE (CPAC-Falcon-10G-B) and 40 GbE (CPAC-Falcon-40G-B). - Page 6 CPAC-TR-40LR-QSFP-10K • CPAC-TR-40SR-QSFP-BiDi Supported DAC cables: • Check Point DAC cables (CPAC-DAC-10G-... and CPAC-DAC-40G-...) are supported only for connection to Check Point Maestro Hyperscale Orchestrators. • Check Point DAC breakout cables 40G to 4x10G (CPAC-DAC-40/10G-...) are supported. Falcon Acceleration Cards Getting Started Guide R80.20...
- Page 7 Supported Falcon Acceleration Cards and Security Appliances Additional interfaces the Gaia on the appliance shows: Number of Names of Acceleration additional additional Module interfaces interfaces <Slot#> <Slot#> -01, eth -02, Falcon-10G <Slot#> <Slot#> -03, and eth <Slot#> <Slot#> -01 and eth Falcon-40G Notes: Slot#...
-
Page 8: Falcon Acceleration Cards
In This Section: CPAC-Falcon-10G-B .......................9 CPAC-Falcon-40G-B ..................... Refer to this generic illustration when you install, remove, or replace Falcon Acceleration Cards in Check Point Security Appliances: Item Description Captive screws Dummy panel for the expansion slot Falcon Acceleration Cards Getting Started Guide R80.20... -
Page 9: Cpac-Falcon-10G-B
Falcon Acceleration Cards CPAC-Falcon-10G-B Item Component Description Port • Off - LAN link is not established Activity • Steady Green - LAN link is established • Blinking Green - LAN activity Link • Speed • Steady Amber - 1 Gbit/sec data rate is selected •... -
Page 10: Cpac-Falcon-40G-B
Falcon Acceleration Cards CPAC-Falcon-40G-B Item Component Description Port • Off - LAN link is not established Activity • Steady Green - LAN link is established • Blinking Green - LAN activity Link • Speed • Steady White - 40 Gbit/sec data rate is selected Falcon Acceleration Cards Getting Started Guide R80.20... -
Page 11: Installing Falcon Acceleration Cards
CHAPTE R 3 Installing Falcon Acceleration Cards Step Description Shut down the Security Appliance from Gaia Portal, or Gaia Clish. Remove the power cords from the power supply units. On the front panel of the Security Appliance, loosen the screws on the dummy panel, or on the installed expansion line card. -
Page 12: Removing Falcon Acceleration Cards
CHAPTE R 4 Removing Falcon Acceleration Cards Step Description Shut down the Security Appliance from Gaia Portal, or Gaia Clish. Remove the power cords from the power supply units. On the front panel of the Security Appliance, loosen the captive screws on the acceleration card. -
Page 13: Configuring The Appliance
Log in to the Gaia Clish on the Security Appliance with these default credentials: • Username - admin • Password - admin Configure the MGMT port on the Security Appliance that connects to the Check Point Management Server and save the configuration: IPv4 Address IPv4 a) set interface Mgmt ipv4-address <... - Page 14 Configuring the Appliance Step Description In your web browser, connect to the Gaia Portal at: IPv4 address of Appliance's Mgmt interface https://< > The Gaia First Time Configuration Wizard opens. Follow the on-screen instructions to configure this appliance as a Security Gateway or a Cluster Member.
-
Page 15: Configuring The Existing Appliance
Configuring the Appliance Configuring the Existing Appliance This section applies to an existing and already configured Security Appliance, into which you need to insert a new Falcon Acceleration Card. Step Description Install the Falcon Acceleration Cards into the Security Appliance (on page 11). Connect to the command line on the Security Appliance. -
Page 16: What Is The Next Step
CHAPTE R 6 What is the Next Step? Falcon Acceleration Cards Administration Guide See the https://sc1.checkpoint.com/documents/Falcon/EN/CP_R80.20_FalconAccelerationCards_AdminG uide/html_frameset.htm. Falcon Acceleration Cards Getting Started Guide R80.20...
