PCI-5000 Series Multifunctional Data

Acquisition Devices

User Manual

Rev. A

Beijing Smacq Technology Co., Ltd.

Smacq.com

Smacq.cn

Table of Contents

Need help?

Do you have a question about the PCI-5000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Smacq Technologies PCI-5000 Series

Page 1 PCI-5000 Series Multifunctional Data Acquisition Devices User Manual Rev. A Beijing Smacq Technology Co., Ltd. Smacq.com Smacq.cn...
Page 2: Statement
Statement Copyright ©2021 Beijing Smacq Technology Co., Ltd. All rights reserved No content of this manual may be reproduced, modified or abridged without prior consent and written permission. Trademark information is a registered trademark of Beijing Smacq Technology Co., Ltd. Smacq The names of the other products and companies mentioned in this document are trademarks or trade names of their respective companies.
Page 3: Safety Requirements
Safety Requirements Warning Only the voltage within the specified range can be connected. Voltage exceeding the specified range may cause damage to the device, and even present a negative impact on personal safety. Check the product specification for detailed reference to the range of voltages that can be connected by each port.
Page 4: Measurement Categories
Measurement Categories Warning For use in measurement category I (CAT I) only. Do not use in measurement category II/III/IV. Use this device to connect signals or make measurements. Measurement categories Note Measurement categories I (CAT I) means that measurements are made on a circuit that is not directly connected to the main power supply.
Page 5: Environment
Environment Temperature Operating 0℃ ~ 55℃ Storage -40℃ ~ 85℃ Humidity Operating 5%RH ~ 95%RH, no condensation Storage 5%RH ~ 95%RH, no condensation Pollution degree Highest elevation 2000 m Pollution degree description Pollution degree 1: No pollution, or only dry non-conductive pollution. This pollution degree has no effect.
Page 6: Table Of Contents
CONTENT Statement ......................1 Safety Requirements ..................2 Measurement Categories ................... 3 Environment ....................... 4 1. Getting Started ..................... 7 1.1. Product introduction ................7 1.2. Function Diagram ................8 1.3. Product specifications ................. 8 1.4. Product unpacking ................11 Precautions ..................11 Check the packing list ................11 2.
Page 7 6.1. Synchronous clock ................26 6.2. External trigger input.................26 6.3. trigger output ..................26 7. Service and Warranty .................28 8. Ordering Information .................29...
Page 8: Getting Started
1. Getting Started This chapter describes the basic functions of PCI-5000 Series Data Acquisition Device, as well as product specifications and precautions in the process of product unpacking. 1.1. Product introduction PCI-5000 series data acquisition device is a synchronize data acquisition device based on PCI bus, which can be used for continuous high-speed signal acquisition and control signal output when installed in a computer.
Page 9: Function Diagram
1.2. Function Diagram Figure 1.1 shows the schematic diagram of PCI-5000 series data acquisition device. Digital system Trigger source: Software trigger External trigger Din trigger PCI bus Sampling clock source: Internal module sampling clock source External sampling clock source Digital I/O FIFO cache Figure 1.1 PCI-5000 series data acquisition device functions...
Page 10 Channel synchronization Range ±10V / ±5V Input coupling mode Input impedance High resistance Small signal bandwidth 1MHz (-3db） Input bias current 200nA Analog input max The ground voltage of each input side does not exceed ±12 V voltage Software FIFO 2 MPts/Ch Onboard FIFO 4096 Pts (shared)
Page 11 Digital I/O Number of channels Ground reference DGND Direction I/O can be set, and the power-on default value can be set. High level: 1.95 V ~ 5 V Digital input voltage Low level: 0 V ~ 1.2 V High level: 3.3 V Digital output voltage Low level: 0 V ~ 0.003 V Highest sampling rate...
Page 12: Product Unpacking
Calibration Recommended warm- No less than 20Minutes up time Recommended 1 year calibration interval 1.4. Product unpacking Precautions To prevent electrostatic discharge (ESD) from damaging the device, please note the following: Please wear a grounding wristband or touch a grounded object first to ensure being ...
Page 13: Installation
2. Installation This chapter describes signal connection and drive installation of PCI-5000 series data acquisition device. 2.1. Connector signal pins distribution Signal connector DB37 Clock synchronization interface Figure 2.1 PCI-5000 signal pins distribution 12 |...
Page 14 19：AI 0 37：GND 18：AI 1 36：GND 17：AI 2 35：GND 16：AI 3 34：GND 15：AI 4 33：GND 14：AI 5 32：GND 13：AI 6 31：GND 12：AI 7 30：GND 11：GND 29：GND 10：GND 28：GND 9：GND 27：GND 8：GND 26：GND 7：GND 25：GND 6：DIO 5 24：GND 5：DIO 4 23：GND 4：DIO 3 22：GND 3：DIO 2...
Page 15: Drive Installation
Signal name Notes Analog input 5 AI 5 Analog input 6 AI 6 AI 7 Analog input 7 Reference ground Input/output 0 DIO 0 Input/output 1 DIO 1 Input/output 2 DIO 2 DIO 3 Input/output 3 DIO 4 Input/output 4 Input/output 5 DIO 5 Trigger signal output...
Page 16 Figure 2.4 Before the driver is installed 15 |...
Page 17 2) Select "PCI Data Capture and Signal Processing Controller", right-click and select "Update Driver". Select "Browse my computer to find driver software" in the pop- up dialog box, as shown in Figure 2.5below. Figure 2.5 Browse my computer for driver software. 16 |...
Page 18 3) Then in the pop-up dialog box, click "Browse" button, locate the operating system version folder corresponding to the driver, and then click "Next", as shown in Figure 2.6 Figure 2.6 Locate the folder where the driver is located. 17 |...
Page 19 4) The computer starts to enter the driver installation process. After the installation is successful, the dialog box shown in Figure 2.6 below pops up, and the driver installation is completed. Figure 2.7 Driver installation is complete 18 |...
Page 20 Figure 2.8 Device Manager after successful driver installation 19 |...
Page 21: Analog Input（Ai
AI here is short for Analog Input. Each analog input channel of PCI-5000 series data acquisition device has an independent ADC, so there is no time difference between the measured data of each channel during analog input acquisition, and multi-channel synchronous acquisition is realized.
Page 22: Single Point Reading
3.3 Sampling rate There is an independent ADC in each analog input channel of PCI-5000 series data acquisition device, so all channels can work at the maximum sampling rate at the same time when analog input is collected 3.4 Trigger...
Page 23: Digital Input（Di
4. Digital Input（DI） This chapter introduces the digital input signal acquisition on PCI-5000 series data acquisition devices. DI is the abbreviation of Digital Input here. 4.1. Signal acquisition mode When the PCI-5000 series data acquisition device performs DI acquisition, it supports the...
Page 24: Trigger
4.2. Trigger The PCI-5000 series data acquisition device provides rich trigger options. The DI acquisition trigger options are shown in Figure 4.1. AiSoftTrig software trigger DiSoftTrig software trigger AoSoftTrig_0 software trigger DI trigger signal AoSoftTrig_1 software trigger DoSoftTrig software trigger...
Page 25: Digital Output（Do
5. Digital Output（DO） This chapter introduces the digital signal output for the PCI-5000 series data acquisition device. The digital input is referred to as DO here, the abbreviation of Digital Output. 5.1. Signal output mode When the PCI-5000 series data acquisition device is utilized for digital output, the following four...
Page 26: Infinite Non-Loop Output Mode
PCI-5000 series data acquisition device DO output update rate can reach up to 10MSa/s/Ch. 5.3. Trigger The PCI-5000 series of data acquisition devices provide a rich set of trigger options, as shown in Figure 5.1, which describes trigger options for the DO output.
Page 27: Synchronization System
6. Synchronization System This chapter introduces the multi-card synchronization system of the PCI-5000 series data acquisition device. The synchronization system has three ports, synchronization clock, external trigger input and trigger output. 6.1. Synchronous clock Synchronization clock is the key signal to ensure the synchronization of multiple devices, which is used to eliminate clock errors among multiple devices.
Page 28 AiSoftTrig software trigger DiSoftTrig software trigger AoSoftTrig_0 software trigger DO trigger signal AoSoftTrig_1 software trigger DoSoftTrig software trigger Globa software trigger Trig_IN external trigger Figure 6.2 Schematic diagram of trigger output circuit 27 |...
Page 29: Service And Warranty
7. Service and Warranty Beijing Smacq Technology Co., Ltd. is committed to its products during the warranty period, if the product fails under normal use in warranty, we will repair or replace defected parts for free. Please refer to the warranty explanation in the box for detailed instructions. In addition to the warranties mentioned in this manual and the warranty note, we do not provide any other warranties, express or implied, including, but not limited to, any implied warranties as to the tradable nature of the product and the suitability of the special purpose.
Page 30: Ordering Information
8. Ordering Information Host Model Notes PCI-5210 8-AI(250kS/s/Ch), 6-DIO PCI-5211 8-AI(500kS/s/Ch), 6-DIO Optional accessories Model Notes DB37CB- DB37 connecting line, double male, 1.5m. 1.5M DB37TB End board, DIN guide rail installation CHF-100B Current sensor, 100A, DC~20kHz, output ±4v CHV-600VD Voltage sensor, 600V, DC~20kHz, isolated differential input, output ±5v 29 |...

This manual is also suitable for:

Pci-5210 Pci-5211
