- Page 1 Welcome Lightcloud Commercial Downlight LCBC6R189TWUNVWS-SS-NS WE’RE HERE TO HELP: 1(844) LIGHTCLOUD 1(844) 544-4825...
- Page 2 Hello Lightcloud Blue is a Bluetooth mesh wireless lighting control system that allows you to control RAB’s various compatible devices. With RAB’s patent-pending Rapid Provisioning technology, devices can be quickly and easily commissioned for residential and large commercial applications using the Lightcloud Blue mobile app.
- Page 3 Safety Information • Risk of electrical shock. Disconnect power at fuse or circuit breaker before installing or servicing. • No user serviceable parts inside. To avoid electrical shock do not disassemble product. • Risk of fire or electric shock. LED Retrofit Kit installation requires knowledge of luminaires electrical systems.
- Page 4 Guide (1) Sticker (1) Tools needed This Lightcloud Blue Commercial Downlight requires very few tools for installation. A screwdriver and a pair of wirecutters will help to install the downlight to a JBox or housing. Compatible Housing Dimensions Optional accessories New Construction Mounting Plates &...
- Page 5 Find a suitable location Add an additional Lightcloud Blue Device • Lightcloud Blue devices should be positioned within to extend network range around corners 60 ft. of each other. • Building materials such as brick, concrete and steel...
- Page 6 Installing your Lightcloud Blue Device (cont’d) 4. Remove J-Box metal plate with existing lamp ballast. Do not dispose. Disconnect all wires from the ballast. (Fig.4) 5. Remove the existing lamp metal conduit (MC) cable from the J-Box. (Fig.5) Fig: 4 Fig: 5 6.
- Page 7 Installing your Lightcloud Blue Device (cont’d) Without Existing Housing 1. Use template inside box to cut hole in ceiling. (Fig.10) Fig: 10 2. Fasten the downlight MC cable to a junction box with MC connector. Wire nut the ground (green) wire in the junction box.
- Page 8 You're all set! Setting Device to Pairing Mode If your Lightcloud Blue Commercial Downlight is already paired, you can reset it by using the below methods. Method 1: Delete from App Open the app and access the device settings for the paired device.
- Page 9 All configuration of Lightcloud Blue products may be performed using the Lightcloud Blue app. Emergency default If communication is lost, the Lightcloud Blue Commercial Downlight may fall back to a specific state, such as turning the Lightcloud Blue Commercial Downlight on.
- Page 10 Lightcloud Lightcloud Blue is a Bluetooth mesh wireless lighting control system that allows you to control RAB’s various compatible devices. With RAB’s patent-pending Rapid Provisioning technology, devices can be quickly and easily commissioned for residential and large commercial applications using the Lightcloud Blue mobile app.
