- Page 1 Soundboard Transducers ~DISQIS, DISQOS~...
- Page 2 Congratulations on the purchase of your Barcus-Berry Soundboard Transducer! With its line of sound board transducers, Barcus-Berry has met a long-standing need for pickups that can be mounted on virtually all types and sizes of acoustic stringed instruments equipped with a sound board. As a general rule, the transducers should be mounted over freely vibrating locations and not over “dead”...
- Page 3 MOUNTING THE BARCUS-BERRY DISQIS (Internal Mount) The Barcus-Berry DISQIS is recommended for installa- tion inside classical guitars, steel string guitars, dul- cimers and similar stringed instruments. The installation may be done inside the soundhole, underneath the soundboard where the transducer will be out of harm’s way.
- Page 4 In such cases, we recommend the Barcus-Berry DIS- QOS (External Mount). The DISQIS comes with four (4) pads of double-sided adhesive foam and Barcus-Berry’s exclusive Fas-Jac Strap Button Mono Jack. In order to determine the position you like for the loca-...
- Page 5 you think best. Should that position prove unsatisfactory, test additional positions in 1/2” inch increments, reusing the same adhesive pad until you find the best position. See Figure 1 as an example.
- Page 6 CAUTION: To prevent damage to the instrument or transducer when removing the adhesive pad, be careful not to pull the wire or bend the transducer. Carefully slide a thin material such as a guitar pick between the soundboard and the pad to free the transducer. Residual adhesive should then be removed from the brass surface of the transducer by rolling it off with your thumb.
- Page 7 Once the ideal position has been determined, mount the transducer on the soundboard at that location with a fresh adhesive foam pad. If you are unsure you can install the transducer yourself, ask your Barcus-Berry dealer to recommend a qualified technician.
- Page 9 The Barcus-Berry DISQOS comes with a 1/4 inch e x t e r n a l m o u n t o u t p u t j a c k , f o u r ( 4 ) p a d s...
- Page 10 of double-sided adhesive foam, and necessary hardware. See Figure 2 for installation suggestion.
- Page 11 For outstanding performance and dependability, you can always rely on Barcus-Berry. Limited Warranty This Barcus-Berry product is warranted for a period of one (1) year from the date of purchase against defects in workmanship and parts. For more info, visit www.barcusberry.com.
