MOP CART INSTALLATION INSTRUCTION
A guide for assembling the Cleanroom Mop Cart with Buckets,
Ergonomic Flat Mop Wringer, and Ergonomic Flat Mop.
WHEEL
CART
BRAKES 1
SCREW, LOCK WASHER &
LOCK NUT
WHEEL
BRAKES 2
BUCKETS
STEP 1.
Open package and make sure all parts are included: cart, buckets (x2), handle, wheel brakes (x2),
screw, lock washer, lock nut.
STEP 2.
Install wheel brakes: depress the wheel brake from the back of the wheel until the brake is engaged. in
rectangular holes. Press down on the brake to lock wheels; lift to unlock.
www.berkshire.com
© 2022 Berkshire Corporation. All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cleanroom Mop Cart with Buckets and is the answer not in the manual?

Questions and answers

Summary of Contents for Berkshire Cleanroom Mop Cart with Buckets

  • Page 1 MOP CART INSTALLATION INSTRUCTION A guide for assembling the Cleanroom Mop Cart with Buckets, Ergonomic Flat Mop Wringer, and Ergonomic Flat Mop. WHEEL CART BRAKES 1 SCREW, LOCK WASHER & LOCK NUT WHEEL BRAKES 2 BUCKETS STEP 1. Open package and make sure all parts are included: cart, buckets (x2), handle, wheel brakes (x2), screw, lock washer, lock nut.
  • Page 2 Install handle: align the handle with screw holes on the side of the cart; ensure the mop handle points to the cart front; insert screw and washer; then tighten the nut. STEP 4. Install buckets: the edge of the grey bucket goes on top of the red bucket. www.berkshire.com © 2022 Berkshire Corporation. All rights reserved...
  • Page 3 Wringer assembly: Open the package and find all included parts–wringer, handle, and locking pin. STEP 6. Insert the handle: ensure holes on the handle align with holes on the metal bar in the wringer; push the handle completely into the insert. www.berkshire.com © 2022 Berkshire Corporation. All rights reserved...
  • Page 4 STEP 7. Insert the lock pin until it is completely flush with the edge of the handle. STEP 8. Place the wringer on top of the cart. www.berkshire.com © 2022 Berkshire Corporation. All rights reserved...
  • Page 5 Install holder clips: insert the holder clip at the position parallel to the mop head; rotate the clip until it is perpendicular to the mop head. STEP 11. Install mop cover: press hand switch to fold mop head; slide on mop cover and flatten mop head. www.berkshire.com © 2022 Berkshire Corporation. All rights reserved...
  • Page 6 COMPLETED ASSEMBLY www.berkshire.com © 2022 Berkshire Corporation. All rights reserved...
