- Page 1 OMNI MIXER & MACRO HOMOGENIZER USER MANUAL REV. A 17258...
-
Page 2: Warranty Information
WARRANTY INFORMATION This manual is a guide for the use of the Omni Mixer and Omni Macro Homogenizers and accessories. Data herein has been verified and validated. It is believed adequate for the intended use of the instrument. If the instrument or procedures are used for... - Page 3 DO NOT attempt to modify any part of the Omni Mixer or Omni Macro. If you experience problems with or have questions about your Omni Mixer or Omni Macro, contact your authorized dealer or call Omni International at 800-776- 4431 or 770-421-0058.
- Page 4 WARNING: The Omni Mixer or Omni Macro must be operated with the chamber assembly resting on a table top or on the bottom of a cooling container to prevent rotating blades from being exposed if the chamber assembly becomes disengaged from the motor, and to minimize the possibility of a broken seal.
-
Page 5: Table Of Contents
TABLE OF CONTENTS Warranty Information ..................... 2 SECTION 1 — OMNI MIXER & MACRO HOMOGENIZERS 1.1 Specifications ...................... 6 1.2 Parts and Accessories ................... 6-7 1.3 Assembly of the Mixer or Macro ............... 7-8 1.4 General Operating Procedures ..............8 1.5 Quick Connect Coupling Assembly ............. -
Page 6: Section 1 - Omni Mixer & Macro Homogenizers
SECTION 1 — OMNI MIXER & MACRO HOMOGENIZERS The Omni Mixer and Omni Macro Homogenizers are variable speed, post-mounted homogenizers. The Omni Mixer is powered by a 600 watt, 18,000 rpm motor, and the Omni Macro by an 1,800 watt, 20,000 rpm motor. -
Page 7: Assembly Of The Mixer Or Macro
SECTION 1 — OMNI MIXER & MACRO HOMOGENIZERS 1.2 PARTS AND ACCESSORIES (cont.) The following components are supplied as part of the Omni Mixer and Omni Macro tool kit (P/N 17104): Description Part Number Quantity Gen Probe Multi Tool 00-402... -
Page 8: General Operating Procedures
1.4 GENERAL OPERATING PROCEDURE The speed of the Omni Mixer or Omni Macro may be regulated to achieve op- timum results when working with different materials. A speed selection knob is located at the side of the unit, as is a separate “OFF” or “ON” switch. When in the “ON”... -
Page 9: Quick Connect Coupling Assembly
1.6 DETERMINING MOTOR SPEED To determine motor speed during operation, a tachometer (not included) may be inserted into the Omni Mixer or Omni Macro through the top of the motor as shown by removing the protective snap cap. -
Page 10: Section 2 - Rotor-Stator Generator Probes
SECTION 2 — ROTOR-STATOR GENERATOR PROBES 2.1 GENERATOR PROBE OPERATION Rotor-stator generator probes are available for use with the Omni Mixer and Macro but are not supplied with the instruments. These probes can be used in a sealed chamber, or for added convenience, in an open vessel environment when aerosols or sample contamination are not a concern. -
Page 11: Operation
2.4 VESSEL RESTRAINT DISK (Optional) The Vessel Restraint Disk (Part # LT-750) can be used with the Omni Mixer and Macro to help reduce splashing and contain aerosols during homogenization. -
Page 12: Section 3 - Sealed Chamber Assemblies
3.1 SEALED CHAMBER ASSEMBLIES Sealed chamber assemblies are available as separately ordered items for use with the Omni Mixer and Macro. They consist of chambers, many of which are fluted to facilitate mixing by inhibiting swirling, gasket screw on cover seals to inhibit aerosol release, a shaft assembly, and a sharpened stainless steel blade, or generator probe. - Page 13 Omni Mixer by using hard materials, such as glass beads. The Omni Mixer will act as a “bead mill”, agitating the chamber while the hard materials do the work. Since sharpness is not essential, a dull blade should be used.
-
Page 14: Sealed Generator Probe Assemblies
3.3 SEALED GENERATOR PROBE ASSEMBLIES Sealed chamber generator probe assemblies are available for use with the Omni Mixer and Macro but are not supplied with the instrument. They consist of chambers, many of which are fluted to facilitate mixing by inhibiting swirling, gasket screw on cover seals to inhibit aerosol release, and a generator assembly. -
Page 15: Positioning The Chamber Assembly
SECTION 3 — SEALED CHAMBER ASSEMBLIES 3.5 POSITIONING THE CHAMBER ASSEMBLY For safe operation, all sealed chamber assemblies attached to the Omni Mixer or Omni Macro must be lowered to the table surface as shown below. 3.6 USING A COOLING VESSEL At speeds above 5,000 rpm relatively high chamber temperatures may be caused from friction during processing. -
Page 16: Section 4 - Dispersating And Impeller Accessories
4.2 DISPERSION IMPELLER ACCESSORIES Two inch diameter dispersion impeller blade accessories are available for the Omni Mixer product line but are not supplied with the instrument. They are specifically designed for dispersion, mixing and blending. These accessories can be used in sealed chambers, or for added convenience, in an open vessel environment when aerosols or sample contamination are not a concern. -
Page 17: Section 5 - Maintenance
Installation of the coupling is the reverse of these steps. 5.3 MOTOR BRUSH MAINTENANCE To a large measure, how well your homogenizer performs its job is deter- mined by the condition of the carbon contact brushes (P/N 61810). If brushes require replacement, the unit may run at a reduced speed and make unusual noises, or it may run sporadically and lose power. -
Page 18: Bearings And Lubrication
SECTION 5 — MAINTENANCE If the brushes are not installed properly they will not contact the commutator and the motor will not run. After replacing the brushes, make sure to remove the flexible rubber coupling, place the motor on a clean surface, and run it freely (no-load, without a generator or chamber assembly attached) for 15 to 30 minutes before using the unit to process samples. -
Page 19: Section 6 - Explosion Drawings And Part Lists
SECTION 6 — EXPLOSION DRAWINGS AND PART LISTS 6.1 OMNI MIXER 115V/220V Part Number Description 17003 Coupling Adapter 17005 Floating Drive Shaft 60028 Flex Rubber Coupling 61672 115V Mixer Motor 61707 220V Mixer Motor 17154 Motor Support Housing 175511 Motor Speed Control (115V) -
Page 20: Omni Macro 115V/220V
SECTION 6 — EXPLOSION DRAWINGS AND PART LISTS 6.2 OMNI MACRO 115V/220V Part Number Description 17003 Coupling Adapter 17005 Floating Drive Shaft 60028 Flex Rubber Coupling 61572-1 115V Macro Motor 61507-1 220V Macro Motor 17571-1 Macro Adapter Plate 17154 Motor Support Housing 175511 Motor Speed Control (115V) 17321-1... -
Page 21: Section 7 - Troubleshooting
SECTION 7 — TROUBLESHOOTING Do not attempt to service the Omni Mixer or Macro in a manner other than those discussed in this manual. For any issue that is unsuccessfully corrected using this guide, please contact your authorized dealer or call Omni International. -
Page 22: Section 8 - Service
SECTION 8 — SERVICE 8.1 CONTACT US Should this product ever require service, please contact Omni International at 1–800–776-4431 or online at www.omni-inc.com 8.2 DECONTAMINATION Should an instrument or component that has been used with radioactive or pathogenic material require factory or field service, comply with the following procedure to ensure the safety of service personnel: •... - Page 23 NOTES:...
- Page 27 NOTES:...
- Page 28 OMNI MIXER & MACRO HOMOGENIZER Omni International, Inc. 935C Cobb Place Blvd. Kennesaw, GA 30144 800.776.4431 770.421.0058 www.omni-inc.com...
