ARTISAN LIGHTING PHUKET PE389 Quick Start Manual

100/364-5 Moo.5 Pracha-U-Thit Rd., Rassada, Muang, Phuket. 83000 Thailand Guongdong AiDimming Electronics Co.,Ltd.
PE389
█

General description:

PE389 dimmer is a 0-10V / 1-10V two-way signal controlled dimmer developed by our company. One knob can achieve the
on-off and dimming functions. At the same time, it also supports the control function of infrared remote controller, smooth
dimming, and can set the minimum brightness.
█

Specification:

Model
Out Voltage
Load Power
OUTPUT
Dimming function
Max control signal
Input Voltage range
Iut put power
Frequency
INPUT
control mode
remote control
Working Temperature
Woking Humidity
ENVIRONMENT
Storage temp.,Humidity
Waterproof grade
Over Load Protection
Short Circuit Protection
PROTECTION
Non-Load Protection

Dimension

Packing
OTHERS
Weight(G.W.)
█
Dimension:
DIMMER
█
Features：
0-10V / 1-10V two signal output functions, smooth and delicate dimming
●
● Metal knob brightness adjustment
● Support infrared remote control dimming on / off to quickly switch brightness
● There are 3 custom scenarios for remote control
● Active control signal, suitable for active and passive dimming power supply
●
Glass panel, metal knob, strong texture
●
Super dimming compatibility
●
Slow on and slow off function
●
Dimming range 0-100%
●
Overheating protection function
●
5-year warranty
PE389
0-10V/1-10Vdc
50mA Max
0-10V/1-10V double singal
50mA
90-250Vac
<2W
50/60Hz
knob dimming/ on and off
IR remote control ( remote range is less 15M)
ta: 45°C tc: 85°C
20 ~ 95%RH, non-condensing
-40 ~ 80°C 10~95%RH
IP20
Use within the specified load range
The output cannot be short circuited, otherwise the dimmer will be damaged and cannot be repaired
constant voltage output when non-load
86×86mm(L×W)
100×92×62mm(L×W×H)
158±10g
33.2mm
10.5mm
Fixed gusset plate
Infrared remote controller
0-10V/1-10V Dimmer
41.3mm
