Summary of Contents for Aluro Aerosol Max
- Page 1 RD/80 Extra Oral Suction Unit Instruction Manual...
- Page 2 CONTENTS Overview Packing List Product Features Specifications Control Panel Filters Cleaning & Disinfecting Control Panel Aerosol Max Structure www.aluroequipment.co.nz // PH 0800 800 805...
- Page 3 The last step purifies through the UVC photo oxygen catalytic sterilisation module, which sterilizes and exhausts air to the outside. In conclusion, Aerosol Max can make the air clean and fresh, improve the cleanliness of the treatment environment and reduce the rate of viral cross-infection.
- Page 4 FILTERS The Aerosol Max/RD80 has five levels/layers. It has a washable primary effective filter, water vapor ab sorbing filter, H13 HEPA filter, an active carbon filter, and an UVC photo oxygen catalytic sterilisation system. The first step uses a washable primary effective cotton filter, then a watervapour absorbtion filter to effectively filter spray, including blood and other large particles.
- Page 5 SPECIFICATIONS Product Aerosol Max / RD80 Voltage AC220V 60Hz / AC110V 60Hz Power 220W Air Volume 340m3/h ≤52db(A) Noise Filtration 0.3 µ m 99% Length of tube 1.4 metres Size l400 x w255 x h595mm Weight 24kg Size of flange...
- Page 6 FILTERS Code Description Replacement Period Replacing RD80 WPF Washable primary effective filter 30 days Pull out tray 1 RD80 WVF Water vapour absorbing filter 2 Months Pull out tray 2 RD80 HEPA H13 HEPA 6 Months Pull out tray 3 RD80 ACF Active Carbon Filter 6 Months...
- Page 7 Machine body Control panel CLEAN DOWN THE AEROSOL MAX ON A PER PATIENT BASIS; Step 1 - Spray the hood cover with hydrogen peroxide 3% inside and outside and leave for 15 minutes before wiping down. After 15 minutes, wipe with a cloth.
- Page 8 AEROSOL MAX STRUCTURE Air inlet Control Panel Lifting Handle Doors to Access Filters Three-in-one switch Filter door latch Universal wheel CONTACT DETAILS Physical Address Postal Address Customer Service 36A Arrenway Drive PO Box 101 613 orders@aluro.co.nz INT PHONE Mairangi Bay...
