AV-CAD AV-5000 LED Installation And Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AV-5000 GSM
Integrated Alarm Control panel &
Installation and Operation
This product is subject to continuous enhancements and therefore
specifications may be changed or altered without prior notice
Item:
4765E_LED (A3BKE)
Rev 04: 27-Feb-2022
E a s y L o a d e r
AV-5000 LED,
(For LED keypads)
Communicator 8 zones
Express Manual
Version 1.00
Edition I
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV-5000 LED and is the answer not in the manual?

Questions and answers

Related Manuals for AV-CAD AV-5000 LED

Summary of Contents for AV-CAD AV-5000 LED

  • Page 1 E a s y L o a d e r AV-5000 LED, AV-5000 GSM (For LED keypads) Integrated Alarm Control panel & Communicator 8 zones Installation and Operation Express Manual Version 1.00 Edition I This product is subject to continuous enhancements and therefore...

  • Page 2: Table Of Contents

    Table of contents Introduction series AV-5000 for LED keypad ............. 3 Tips to first time installer..................3 Revision changes ....................3 Keypad AV-701, AV-702 short description............4 2. Wiring Devices Alarm Panel................6 2.1 AV-5000 Zone Wiring .................. 6 2.2 Tamper per zone & EOL wiring ..............6 2.3 EOL Zone Wiring..................

  • Page 3: Introduction Series Av-5000 For Led Keypad

    Introduction series AV-5000 for LED keypad The series 5000 alarm panels for LED keypads are simple, easy to customize and programming. Series 5000 models This is an express manual for series 5000 alarm panels for LED keypad supplied as technical reference; with each alarm panel we provide a short format manual. Model AV5009_GRND is GSM only SMS messaging and dial, not supports PSTN dial.

  • Page 4: Keypad Av-701, Av-702 Short Description

    Group Bypass explained in the keypad section. For full details refer to the keypad section in this manual and the keypad manual. The AV-5000 LED alarm panel board carries a specific identification label (refer to wiring diagram) that indicates the software version and panel type.
  • Page 5 Warranty and technical support If end user or a person on his behalf change product, wrong wiring or programming our product he do so on his own risk, product warranty is void is such case. Av-Gad Systems Ltd can't technical support such customers, contact local technical or installer. Warranty terms are published separately.

  • Page 6: Wiring Devices Alarm Panel

    2. Wiring Devices Alarm Panel 2.1 AV-5000 Zone Wiring The AV-5000 provides two ways of zone wiring: None EOL (EOL = end of line) resistor loop (factory default), EOL resistor loop only for zone 4 and 8. The EOL loop protects the zone lines against tampering.

  • Page 7: Eol Zone Wiring

    2.3 EOL Zone Wiring The AV-5009 factory default is 8 zones none EOL zones. If EOL mode is required move jumpers as shown in figure 2.2. The zones are referred to –V. If zone 4 or 8 selected as EOL type add in series with the 2.2.K (zone 4) or 4.7K (zone 8) resistor and the sensor contacts (relay.
  • Page 8 F i g u r e 2 . 4 : W i r i n g L E D k e y p a d t o c o n t r o l p a n e l Wiring terminal of keypad type AV-702 (in above figure) and for AV-701 keypad are identical.

  • Page 9: Pir As Eye Spy Ii Wiring

    2.5 Motion detector PIR as Eye Spy II wiring The PIR (Passive Infra Red) detector is a motion sensor that upon detection opens the relay contacts, this activated the alarm panel. In higher security installation it's recommended using EOL resistors that protect the wires from being tampered. Figure 2.5: W iring PIR or similar detector to control panel 2.6 Siren Wiring The siren output is protected by Electronic Fuse.

  • Page 10: Back-Up Battery

    Warning, siren/s current should not exceed 0.3 Ampere Bell mode is factory default; in Bell mode install a 12V DC siren, which contains sound driver or electronic modules that powered by 12V DC. Bell Mode converts Siren outputs into 13.6V DC outputs (no sound is issued). Bell mode is applicable for driving self-powered sirens or bells, or combined sirens and strobes.

  • Page 11: Telephone Line (Central Station No Available)

    When wiring DC power supply to alarm panel; the (+) connect to the upper AC wires terminal and the (-) to the lower AC marked terminal. Verify the ground is connected. F i g u r e 2 . 7 : W i r i n g p o w e r s u p p l y 1 4 V m a x i m u m 3.

  • Page 12: Svm - Synthesized Voice Module Svm-40, Svm-42

    For dedicated central station applications the GisMo sends SMS direct to patrol or to central control and patrol man. Central station software is not included. 3.3 SVM – Synthesized Voice Module SVM-40, SVM-42 SVM-40, SVM-42 models are not working with GisMo (GSM adapter) panels. 3.4 Telephone and SMS address Telephone numbers There are 13 telephone numbers, 16 digits each.

  • Page 13: Enter User Programming & Set New User Code

    3. Code number 09 programming Code (Installer Code) - Code No. 09 enables entering into programming mode (system features programming) at Installer level. The factory default programming code is ‘1 9 9 4.’ The programming code may be installer-programmed. Installer code does not Arm or Disarm system.

  • Page 14: Auto Arming & Passive Auto Arming

    2. While four LEDs are blinking, enter code No. 1 (default 1 2 3 4) 3. To erase an existing code: Enter user index number (01, 02, 03..), Hold Down simultaneously the '*' and ' #' keys, followed by #, E (erased) will be displayed. The Master (code number 01) cannot be erased.
  • Page 15 Hold-Down Functions: Siren Key 1  SIREN TEST Shunt Display Key 2  SHUNT DISPLAY Displays shunted zone(s). Status Key 3  STATUS DISPLAY Displays troubled or malfunctioning zone(s), open zone/s displayed Delay Delete Key 4  DELAY DELETE (INSTANT PROTECTION) Cancels Entry delays in zones selected as ‘Delayed’...

  • Page 16: Group Bypass (Home Mode)

    Hold-down key 6 and then key 1, before the computer and modem connect (dial) the control panel. The panel will acknowledge the command with two beeps and display an ‘A.’ The feature remains active for 5 minutes after entered, enabling to remotely program (from remote computer) the panel.
  • Page 17 There is no "beep" at the keypad until an alarm occurs, or until Group Bypass is canceled. When the keypad LEDs turns off after Arming (requires programming), touching the keypad will activate the LEDs for 5 seconds. 5.3 Key Zero Hold-Down functions & Events History To get last 10 events by SMS: Hold down 6 than hold down key 4.

  • Page 18: Led Dual Keys Hold-Down Functions

    Browsing through Events History Keys used for browsing: Shunt  Skip forward to next event  Skip backward to previous event Program Display  Display current event again  Cancel History Event Mode and exit Chime Reset Upon display of last event, if an attempt is made to move forward (key 2), a blank sign – is displayed, along with a warning beep indicating that it is the last event.

  • Page 19: Keypad Main Operations

    200 and 05 Restore all codes to factory default 200 and 08 Set all zones to none EOL (cancels double zones) 200 and 21 Reserved 200 and 22 Reserved 200 and 69 Restore program to default 5.6 Keypad Main Operations Function Keypad Operation LED’s...
  • Page 20 For easier detailed alarm history, use the downloaded from panel to remote computer. History queue log of up to 250 events are displayed at panel keypad and in the EasyLoad PC software. Shunt Siren Display and Setting of System Time: Hold down key ‘0’ and then hold-down key ‘1,’...

  • Page 21: Keypad Sounder

    5.7 Keypad Sounder The Keypad sounder (buzzer) enhances the use of system operation and serves as a local alarm device (requires programming). The sounder emits sounds in the following instances: OPERATION SOUNDER RESPONSE  Pressing of any key Short confirmation beep ...
  • Page 22 Status LED-Green AV-5000 alarm panel System Disarmed Blink slowly Some zones are open ON steady All zones OK Some zones have been tampered Blink fast Shunt LED-Orange AV-5000 alarm panel ON steady Some zones are bypassed Blink slowly Group bypass entered 8 seconds after Armed with Group Bypass Blink slowly Fire LED-Red...

  • Page 23: Programming Sheet Version 1.00 Led

    7. Programming Sheet Version 1.00 LED Factory Default Program marked with ( ); Blank Square means no default program Part 1: TELEPHONES & SMS Subscribers (00 = No, 01 = Yes).  Feature Send SMS SMS @ Period Test SMS Max SMS Time stamp SMS Close/Open...
  • Page 24 3. System Features & Times (00 = No, 01 = Yes) Address Feature Default Address Feature Default     D i a l e r F e a t u r e s A r m / D i s a r m K e y Instant dialing on entry delay (0=No) Use last zone (8 /16) as key input (0=No)
  • Page 25 4. ZONE 1 to 16 FEATURES (> refers to the value setting address) Zones 1 to 8 Zones 9 to 16 Zone Number  10 11 12 13 14 15 16 Feature  Add. Group 1 Add. Group 2 Zone In Use Entry/Exit Delay 1 >062 Entry/Exit Delay 2...

  • Page 26: Powering Up & Programming Examples

    5. ZONE 17 to 32 FEATURES (> refers to the value setting address) Zones 17 to 24 Zones 25 to 32 Zone Number  17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Feature ...

  • Page 27: Reset System To Default Programming

    8.2 Reset System to Default Programming In case you made programming changes and the system operation is miss functions it is recommended to set system to the factory defaults program. Warning, this function erases all codes and system programming settings. Apply as below: 1.
  • Page 28 EXAMPLE 1: ‘P’ is displayed and two left-most LEDs are blinking. 1. Program zones 1 and 4 as ‘Exit/Entry Delayed 1’ (zone type). 2. Address 208 represents the ‘Exit/Entry Delayed 1’ zones. 3. Press 208; current value of this address is ‘1’ (factory default program.) Three LEDs will blink and a ‘1’...

  • Page 29: Gismo Gsm Module Add On

    9. GisMo GSM module add on 9.1 GSM for series 5000 SMS format To identify the GSM; The Gismo PCB board with antenna plug located at the left-upper side in the main control panel enclosure. Pack includes GSM RF antenna. Before power up always connect the antenna to prevent damage to the GSM module.

  • Page 30: Programming Gsm And Dial Features

    9.2 Programming GSM and Dial features To setup the panel wire the keypad model AV-701 or AV-702 (refer to main installation manual). With power down insert the SIM card and connect the GSM antenna. Power up with DC only (without battery), as all works connect the battery. Hold down key 8, enter 1 9 9 4 (programming code), P is displayed indicating you are in PROGRAM mode.

  • Page 31: Wiring Diagram

    10.1 Wiring Diagram AV-5009 LED GSM ready Wiring Diagram WARNING: To prevent electrical 12V SLA shock, disengage the BATTERY AC power and PC88C-5288 AV-5009 LED disconnect the (GSM READY) telephone line before SERIAL Red wire servicing this unit. To GSM to + -BATTERY Auxiliary Power...
