User Manual AIRYN ATC-T series thermal cameras Version 1.3 Open Box Wiring and Installation Installation Wiring and power on Access to management UI Body temperature management Initial calibration System settings Adjustment - Body temperature calibration Display Mode - Display layout, resolution and temperature setting...
Page 2: Open Box
Open Box The box content includes 1x ATC-T series (ATC-TNC or ATC-T01) thermal camera, 1x HDMI right-angle cable and 2x AC to USB power adapters including 1x USB type-c cable. Wiring and Installation Installation On the rear side of the camera there is a standard screw pin hole for mounting the camera on a tripod.
Page 3: Wiring And Power On
A red light indicates that the power is on. No light indicates that the power is off. Plug in the power cable and the camera will turn on automatically. Press the power button for 2 seconds and the camera shuts down. Doc# - AIRYN-ATC-T-Series - v1.3...
Page 4: Access To Management Ui
(3) from a person to the camera for the most accurate body temperature measurement. The Airyn ATC-T series thermal camera can act as a stand-alone device or as a network device. It triggers an alarm and sends out a notification when the body temperature exceeds a certain threshold set by the operator.
Page 5: System Settings
HDMI monitor or screen. Scroll down to select the display resolution and / or select the preferred temperature setting (Celsius or Fahrenheit). Recommended resolution external monitor: 1920x1080. Doc# - AIRYN-ATC-T-Series - v1.3...
Page 6: Network - Static Or Dhcp
RTSP protocol through the RJ45 port using the following URL: rtsp://IP of physical port:8554/thermal rtsp://IP of physical port:8553/visible The option “Local out” is to switch the video stream back to HDMI output. Doc# - AIRYN-ATC-T-Series - v1.3...
Page 7: Shutdown System
Do not forget to choose the option “RTSP out” to direct the video stream via the RTSP protocol through the RJ45 port. Please download the color map from the link below: The color map file of body temperature camera Doc# - AIRYN-ATC-T-Series - v1.3...
Page 8: Recommendation For Deployment
Recommendation for deployment Refer to below recommendations for best accuracy results: Doc# - AIRYN-ATC-T-Series - v1.3...
