Summary of Contents for Acustek SWORD-24s
- Page 1 SWORD-24s Extendable Handheld Non-linear Junction Detector Operational Manual COUNTERMEASURES SURVEILLANCE FORENSICS...
- Page 2 SWORD-24s Non-linear Junction Detector SWORD-24s Extendable Handheld Non-linear Junction Detector Harmonic test samples (2nd, 3rd) Headphone Adaptor Non-linear Junction Detector Cable Hand-held telescopic pole...
- Page 3 PART...
- Page 4 SWORD-24s Non-linear Junction Detector Schematic Diagram of Product Structure Antenna: Transmit and receive test signals. Headend: Display device status, such as battery level, transmit power value, second harmonic and third harmonic signal strength; Central control keys: Including power button, transmitting power adjustment button, receiving sensitivity adjustment button, sound adjustment and vibration adjustment button.
-
Page 5: Use Scenarios
PART Use Scenarios Can be widely used in government, public security, prison, judicial, military, SWORD-24s education examination and personal privacy protection, etc. Enterprise and commercial secret protection: Detect unauthorized BUSINESS SECURITY electronic devices hidden in important conference rooms or confidential offices of the company, such as eavesdroppers, mobile phones and devices containing SIM cards, etc.. - Page 6 SWORD-24s Non-linear Junction Detector Operation guide 1. Central Control Key Operation Area Power on button： On/off button, press and hold for 2 seconds to switch on, press and hold for 2 seconds to switch off, with indicator. Tx button： Transmit power adjustment button, divided into high, medium and low, with indicator light.
- Page 7 PART Transmit Power Strength Indicator Indicates the received second harmonic signal strength Indicate the received third harmonic signal strength When a suspicious electronic device is detected in the target area, the second harmonic signal strength is significantly stronger than the third harmonic signal strength and the electronics icon is displayed on the screen.
- Page 8 SWORD-24s Non-linear Junction Detector 3. Interface The screen interface mainly displays the battery level, the alarm mode, the transmit power level and the strength of the received second and third harmonic signals. The detection process and results are as follows:...
- Page 9 PART General Spcifications Product working frequency band: 2.400GHz Frequency range： 2.404GHz - 2.472GHz Receiving 2nd~3rd harmonic range: 4.808GHz-4.944GHz， 7.212GHz-7.416GHz Pulse mode transmit power (max): 0-1W Receive sensitivity: ≤-125dBm Receive dynamic adjustable range: 30dBm Battery working time: 4.5H Battery type: Lithium battery Interactive interface: LED displays received harmonic signal intensity Audio prompts are supported and headphones can be connected...
- Page 10 Q: What can I do if it does not start when I press the power button? Normal boost requires long press on the power button for more than 3s; Long press on the power button for 3s and still can't turn on. It may be that the battery has run out of power. You need to connect the power adapter for charging.
