Summary of Contents for All-Wind AW-1000s
- Page 1 Windmill Generator AW-1000s Low-Speed Synchronous Permanent Magnet Generator Quick guide...
-
Page 2: Table Of Contents
Table of contents Privacy policy / Rules for handling3 Safety precautions 4 Mounting instructions5 Generator AW-1000s 6 Specifications 7 Recommended connection 8 Warranty policy / Return material procedure 9... -
Page 3: Privacy Policy / Rules For Handling3
Privacy policy / Rules for handling Thank you for buying an All-Wind product Trademark names are registered trademarks “All-Wind” and “CCSC Technology” are registered trademarks of All-Wind GmbH All other brand and product names are trademarks of their owners Product code... -
Page 4: Safety Precautions 4
Make design changes Use the generator, if its body or shaft is damaged The connection and attachment of All-Wind generators may only be executed by specialized windmill installation companies Connection to the site’s distribution grid should be performed when installing the windmill by qualified personnel in strict compliance with electrical equipment... -
Page 5: Mounting Instructions5
• 10 mm for aluminium alloy In Fig 2 you can see the recommended mounting scheme for the AW-1000s generator Installation and mounting procedure: Insert the bolts into mast platform holes and fix them using nuts DIN 934-M8 (6 pcs) and... -
Page 6: Generator Aw-1000S 6
Generator AW-1000s М8 16,8 26,6... -
Page 7: Specifications 7
Specifications Electrical specification Rated Power (W) 1000 Output power range (W) 0 - 1800 Rotational speed range (RPM) 0 - 300 Number of phases Phase voltage range, AC (V) 0 - 120 Frequency (Hz) 0 - 120 Phase current at rated output (A) Phase resistance (Ω) Output wire square section (mm²) 4 x 25, 1 x 4 (grounding) -
Page 8: Recommended Connection 8
Recommended connection AW-1000s The generator should be connected to а special controller designed for output power that is at least 15 times greater than the rated power of the generator It is forbidden to use controllers extending the load by means of “short circuit” It is prohibited to connect the generator to electrical household devices directly... -
Page 9: Warranty Policy / Return Material Procedure 9
Warranty policy / Return material procedure All-Wind products are warranted for 3 years from the date of purchase This warranty is only valid in EU countries All-Wind GmbH manufactures its products from parts and components that are new or equivalent to new in accordance with industry standard practice... - Page 10 For more information please go to the All-Wind homepage: www.all-wind.com The technical specification and dimensions of the parts may be changed without prior notification by the manufacturer. Copyright ©2013 All-Wind GmbH. All Rights Reserved. Printed in EU. Version 30 20150126...
