Summary of Contents for AeronSmart S5F2
- Page 1 AeronSmart Let’s make Life Smart User Guide Please read this guide before installing and operating AeronSmart device and keep it for future reference.
- Page 2 It also facilitates two-way switching. To operate AeronSmart device, we request you to register your account at Aeronsmart App or www. aeronspire.in; and use the features to its fullest. Yours Faithfully...
- Page 3 AeronSmart Table of Contents S. No. Topic Safety Instructions Introduction Part Names and Functions AeronSmart S5F2 Connection Installation AeronSmart App/Web Setup and Configuration with device Troubleshooting Disclaimer Support...
- Page 4 Do not connect devices such as AC, heater, electric iron (load above 450 Watts) through this device. It may cause failure of this device. To use such devices, we recommend you to use AeronSmart Wi-Fi power switch. Configure a circuit so that device is turned on first and then the external power supply.
- Page 5 AeronSmart with a different voltage rating or incorrect wiring may cause a fire or failure. Do not cover this device entirely. When disconnecting the cable from the device, do not pull the cable by the cable part. Pulling the cable connected to the device may result in malfunction or damage to the device or cable.
- Page 6 AeronSmart Introduction - AeronSmart Wi-Fi Switch basics AeronSmart Wi-Fi switches provide you with wide variety of Wi-Fi devices through which you can make your life smart. AeronSmart Wi-Fi switches are specially designed so that you can control your electrical appliances at your fingertips.
- Page 7 AeronSmart Part Names and Functions...
- Page 8 Phase: Phase of AC mains is given through this terminal. Load connectors: Any electrical appliance such as bulb, fan, tube light, etc. that you want to control with AeronSmart Wi-Fi switches is connected through these terminals. Only phases of loads are connected through these terminals.
- Page 9 AeronSmart Status (green) LED: When turned on indicates that device is online.
- Page 10 These load terminals provide variable output voltage which controlled using F6 and F7 AeronSmart app. Upto 450 Watt of load can be connected to each terminal. This terminal supplies phase to load. One terminal of each switch must be connected to this...
- Page 11 AeronSmart Restart Switch This switch restarts device. This indicates that device is Power LED powered on. This indicates that device is Status LED online.
- Page 12 AeronSmart AeronSmart S5F2 Connection This device is designed in such a way that you can connect it anywhere like your home, office, hotels, etc. without changing your existing electrical connection. Refer to the following diagram to connect this device.
- Page 13 AeronSmart...
- Page 14 Connect phase of each load to each load connector terminals. Do not connect load rated above 500 W with any load connector terminal of AeronSmart device model S5F2. Connect neutral of all loads together neutral of AC power supply. ...
-
Page 15: Installation
4. Your device will automatically connect to your open Wi-Fi. Now your device is online and its green LED will turn on. 5. Open AeronSmart App. If you are using application for the first time then create an account and if not then login to your account. - Page 16 AeronSmart AeronSmart App/Web Setup and Configuration with device Signing In If you have already signed up in AeronSmart App, input your Mobile Number/E-Mail and password to login. If you are a new user, click on “Create Account” complete the sign up process.
- Page 17 AeronSmart Signing Up On “Create Account” page, fill your relevant information and click on “Send OTP” to get OTP.
- Page 18 AeronSmart OTP Verification Insert six digits OTP sent to your mobile number complete the process.
- Page 19 AeronSmart Home...
- Page 20 AeronSmart On home page, you can add device by entering valid serial number printed on top/bottom of the device.
- Page 21 AeronSmart Home your smart devices installed at home/workplace are visible on home page.
- Page 22 AeronSmart Device Control Dashboard You can operate all your switches from control dashboard. There is a personalized scheduling option shown as a blue and green colored icon. Blue scheduling icon indicates that this switch is unscheduled. Green scheduling icon indicates that this switch is scheduled.
- Page 23 AeronSmart Setup & Information In “Setup and Info.” page, you can get device details and device activity history as well as you can enable/ disable your mechanical switch board. If you disable mechanical switch board then you can operate your...
- Page 24 AeronSmart Edit Give appropriate names to smart devices and switches connected to your electrical appliances. You can provide two Wi-Fi SSID(Wi-Fi names) and their passwords. It will search for SSID, if available; the device will be connected to it. Otherwise, it will search for 2 SSID, if available;...
- Page 25 AeronSmart Daily and One-Time Schedule Scheduling facility allows you to conveniently schedule your smart appliances in given time range. You can schedule for wake up and sleep time, workplace in and out time and for specific work. This facility brings ease in your life...
- Page 26 AeronSmart Add User...
- Page 27 Administrator can give device limited access to their family members and friends. Administrator must provide a unique password to each user. A user can logging in to AeronSmart App/Web by administrator’s Mobile Number/E-Mail and a unique password assigned by the administrator.
- Page 28 AeronSmart Device Users All the device users added by administrator are visible here. You can edit user’s details by clicking on User (like Princess). Delete User...
- Page 29 AeronSmart Delete User An administrator can delete desired user. Once deleted, that user cannot be able to login.
- Page 30 AeronSmart Voice Control Device switches operated by voice command also. Voice command can be activated by signature word “Moon”. Each voice command should start with signature word “Moon”. For instance, “Hi Moon, turn on my bedroom tube light”. “Moon, can you please turn...
- Page 31 AeronSmart Each voice command must include 3 words: i) Location of Board (bedroom, study Room, etc.) ii) Switch Name ( tube light, fan, TV, etc) iii) Action (turn on, turn off, tell state, tell status, increase, decrease) For instance, “Moon turn off my bedroom tubelight”.
-
Page 32: Troubleshooting
AeronSmart Troubleshooting Problems Possible solution → Make sure the AC power supply is connected to AC power supply connector. No loosen Power LED is not ON connection. → Power supply must be within range of 200V to 250V AC. → At the time of installation, it requires an Green LED is not ON at open Wi-Fi connection. - Page 33 AeronSmart → Make sure that the load is connected either Output voltage cannot be varied using app to load connector F6 or F7.
- Page 34 AeronSmart Disclaimer AeronSmart product’s specification, features and data are subject to change without notice to improve functionality, reliability and design. AeronSmart products have been tested at different working conditions and found correct for best performance. Aeronspire takes no guarantee and responsibility regarding suitability of products for any abnormal environment.
- Page 35 AeronSmart Support For any query regarding our products, feel free to ask. Our customer executive will reach you within 24 hours to answer your query. E-mail info@aeronspire.in What’s App +91-7762820555 Phone +91-7762820555 Address N/B Tata Park Gate No – 1...
