ARTESYN EMBEDDED TECHNOLOGIES ATCA-7350 Quick Start Manual

ATCA-7350
Quick Start Guide
P/N:6806800H72C (August 2014)
1
What's in the box?
Make sure you receive all items of your
shipment:
• One ATCA-7350 blade
• One RTM-ATCA-7350
• One printed copy of Quick Start Guide
(this document)
• One printed copy of Safety Notes Sum-
mary
• Any other optional items that you
ordered
When installing or servicing the
module or accessories, strictly
observe the safety precautions in
the Safety Notes Summary. Other-
wise, personal injury or property
damage may occur.
2
Observe ESD-safe
measures
• Use either a properly grounded ESD wrist
strap or make sure that you are working
in an ESD-safe environment.
• Connect your ESD wrist strap to the ESD
connector at the front or the rear of the
system.
3
Checking Installation
environment
• Leave enough space around the cab-
inet. Prevent air blocking of fans and
provide controlled ambient air at
shelf air-inlet to ensure sufficient air-
flow and appropriate heat exchange
in the shelf.
• Consider heat dissipation when you
choose slots to install blades. If the
shelf is not fully configured, install
the blades in scattered slots. Unoc-
cupied slots must be protected with
• appropriate blank filler blades to
prevent air leaks.
4
Installation of
RTM-ATCA-7350
The following procedure describes the
installation of RTM-ATCA-7350. It
assumes that your system is powered on.
If your system is powered off, you can dis-
regard the blue LED and thus skip the
respective step. In this case it is a purely
mechanical installation.
1. Wear the ESD-preventive wrist strap.
2. Take RTM-ATCA-7350 out of the anti-
static package.
3. Fully open the upper and lower ejector
handles of the RTM.
4. Align the upper and lower sides of
RTMATCA-7350 with the guide rails
(the edges of the slot). Slide RTM-
ATCA-7350 along the guide rails until
the positioning pins of RTMATCA- 7350
are inserted in the positioning
5. holes in the shelf. The LEDs; OOS LED,
Blue LED, and healthy LED are on.
6. Make sure that the handles are in the
open position.
