Summary of Contents for Audio Phonique PSE1605
- Page 1 O W N E R ’ S M A N U A L PSE1605 M O N O P O W E R A M P L I F I E R S S T A T E M E N T...
- Page 2 We recommend that you read and follow this manual before using Audio Phonique PSE1605 for the rst time, so that you can install its tubes correctly and avoid any problems caused by improper handling. Should you have any questions about Audio Phonique PSE1605, please feel free to ask us directly or our distributors.
-
Page 3: Table Of Contents
INTRODUCTION ABOUT US OUR R&D TEAM OUR DESIGN PHILOSOPHY OUR MANUFACTURING AND QUALITY CONTROL OUR STATEMENT LINE HOW TO USE YOUR AUDIO PHONIQUE PSE1605 OVERVIEW UNPACKING INSTALLATION TUBES REAR PANEL TECHNICAL SPECIFICATIONS CAUTION CONTACT... -
Page 4: About Us
We guarantee unforgettable musical experiences presented in visually beautiful and timeless forms. All Audio Phonique products are assembled at our factory located In Poland, which allows us to maintain strict quality standards and have full control over the entire production process. -
Page 5: Our R&D Team
He also supervises all design processes, cooperates with subcontractors and handles the nal stage in form of critical listening sessions and related product tuning. Audio Phonique was established by audio acionados, who rely on international specialists highly qualied in military, material and industrial design engineering. -
Page 6: Our Design Philosophy
OUR DESIGN PHILOSOPHY „Everything should be made as simple as possible, but no simpler.” Albert Einstein We believe that excess electronics harm music that shouldn’t be changed or improved but left as is. That’s why elegantly simple audio circuits are our way to achieve beautiful sound, even though paradoxically it’s the route uphill from the engineering point of view. -
Page 7: Our Manufacturing And Quality Control
Electronic components inside our products are subjected to measurements and strict selection, which to us is the only way to guarantee their quality, repeatability and compliance with reference models. Prior to leaving our facility each Audio Phonique product is burned in and then evaluated in our listening room. -
Page 8: Our Statement Line
DSD. But above all else, Audio Phonique DAC DHT is a no-compromise D/A converter that cannot be ignored, while its polished surgical steel chassis will please even the most demanding... -
Page 9: Overview
Their velvet sound characteristic and low distortion allow for very loud playback regardless of a music genre. Audio Phonique PSE1605 mono ampliers will take you to the world of limitless space full of dynamic vibrant sound sources and associated extremely high emotional content. -
Page 10: Unpacking
Should you notice any visible marks of misuse, contact your dealer immediately. 4. Contents of the package: - two Audio Phonique PSE1605 mono power ampliers - two pairs of EML1605 output power tubes - one pair of EML20B driver tubes - one pair of EML274B full-wave rectier tube... -
Page 11: Installation
INSTALLATION 1. Connect and use the product in accordance with this manual. 2. The product should be powered only from fully functional grounded mains outlets 3. The product should be powered with AC voltages specied on its rear panel near the power inlet. -
Page 12: Tubes
TUBES It is very important to install all tubes correctly and as shown on the diagram below. All tubes feature 8-pin (octal) sockets and their incorrect installation may damage the product. Prior to installing tubes make sure that the product is disconnected from the mains and has its power cable removed. -
Page 13: Rear Panel
REAR PANEL 1. Speaker binding posts to connect a speaker in accordance with their colors (white/red) and impedance (0/4/8Ω). 2. AC inlet (IEC) with the main on/off switch and fuse compartment. 3. Balanced (XLR) and single-ended (RCA) inputs for a preamplier's corresponding outputs. -
Page 14: Technical Specifications
TECHNICAL SPECIFICATIONS Input impedance: 100kΩ Output impedance: 4/8Ω Input sensitivity: max. 5Vrms Output stage topology: parallel class A Power tube: 2x EML1605 Driver tube: EML 20B Rectier tube: 274B Gain: 20dB Chassis: polished surgical steel Self-noise: 1.5mV RMS Power consumption at idle/max: 500W Input voltage: 115V/230V... -
Page 15: Caution
BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED AUTHORIZED SERVICE PERSONNEL FOR SERVICING. THE AUDIO PHONIQUE is not responsible for any damages due to external causes, including but not limited to, improper use, problems with electrical power, accident, neglect, alternation, unauthorized repair, improper installation or improper testing. -
Page 16: Contact
CONTACT Should your Audio Phonique product require servicing in the future, please contact your local dealer or Audio Phonique directly. AUDIO PHONIQUE Marketing Investment Group ul. Rymarska 7 05-800 Pruszków, POLAND NIP: 522-000-87-56 VAT-EU: PL522-000-87-56 mobile\whatsapp: (+48) 509720722 info@audiophonique.com www.audiophonique.com... - Page 17 The entire Audio Phonique team wishes you an amazing experience!
