R
TC6 GLASS STAND
Easy Assembly Instructions
May we take this
opportunity to thank
you for purchasing
this TC6 Glass Stand.
We strongly suggest
that you carefully
study these assembly
instructions before
attempting to assemble
the unit, and that you
observe the listed
precautions.
Please read these precautions before assembling and using this unit.
1
Take care when unpacking to avoid scratching the glass.
2
Ensure plastic spacers are used on both sides of the glass shelves.
3
Check stand is sitting level, adjust the feet as required.
4
Do not put very hot, or cold, items directly on the glass shelves.
5
Do not allow any hard, or sharp, objects to come in contact with the glass shelves.
6
Do not use abrasive cleaners on the glass, use only a damp cloth and glass/mirror cleaner.
If a glass shelf is chipped or broken, replace with the same type of glass only. Contact the
Acoustic Solutions Helpline on 01327 340601 for any replacement items. This line is manned
from 9:00am until 4:30pm, Monday to Friday.
CAUTION Do not overload glass shelves.
Maximum load per shelf is 15Kgs
REV: 1/053/1.1
Advertisement
Summary of Contents for RAX TC6
- Page 1 May we take this opportunity to thank Ensure plastic spacers are used on both sides of the glass shelves. you for purchasing this TC6 Glass Stand. Check stand is sitting level, adjust the feet as required. We strongly suggest that you carefully Do not put very hot, or cold, items directly on the glass shelves.
- Page 2 Component parts and fittings contained in the box Remove all parts from the carton and inspect them. If you find any damaged or missing parts please contact the Acoustic Solutions Help Line on 01327 340601 for replacements. This line is manned from 9:00 am until 4:30 pm . Part No Name Quantity...
- Page 3 ASSEMBLY Open the glass packaging taking care not to scratch the glass. Remove & store glass shelves safely. Screw feet (2) into each of the size 3-A supporting tubes. Place plastic washer (5) over thread on opposite end of each tube.
- Page 4 ASSEMBLY Place a thread protection spacer (4) over the thread of each tube. Take the first glass shelf making sure that you handle with care. The curved edge of the Place each of glass shelf faces to the front support tubes of the stand.
- Page 5 ASSEMBLY Take support tubes 3-D and screw onto the four NOTE: Either columns threads on support 3-D or 3-C can be fitted tubes 3- A and at this stage, dependent then place another on what configuration four washers and suits you. thread protection spacers over the threads on support...
- Page 6 3-B. Adjust the feet to the height required, ensuring the stand is level in the location you want to use Now your TC6 glass stand should be assembled rigidly. We hope this stand has all the features you require.
