dellonda Deluxe DG117 Assembly Instructions

Firepit, fireplace, outdoor patio heater, cooking grill & poker

Dellonda Deluxe Firepit, Fireplace, Outdoor

Patio Heater, Cooking Grill & Poker

Model No. DG117

Thank you for purchasing a Dellonda product. Manufactured to a high standard, this product will,

if used according to these instructions, and properly maintained, give you years of trouble free performance.

DG117 Issue:1 03/08/21

www.dellonda.co.uk

Table of Contents

Need help?

Do you have a question about the Deluxe DG117 and is the answer not in the manual?

Page 1 Patio Heater, Cooking Grill & Poker Model No. DG117 Thank you for purchasing a Dellonda product. Manufactured to a high standard, this product will, if used according to these instructions, and properly maintained, give you years of trouble free performance.
Page 2 It is strongly recommended that hands are protected with a pair of work gloves. • Keep children and pets away from the area. Contents Description. Qty. Handle Mesh screen Grill Wood grate Grill supports Fire bowl Poker M6 x 10mm bolt M6 nut www.dellonda.co.uk...
Page 3 • Step 2: Attach the leg (G) to the bottom of the fire bowl (F) with two M6 x 10mm bolts (AA). Repeat with the other two legs. • Step 3: Attach the handle (A) to the mesh cover (B) with two M6 x 10mm bolts (AA) and M6 nuts (BB). www.dellonda.co.uk...
Page 4 No liability is accepted for incorrect use of this product. Guarantee is 12 months from purchase date, proof of which is required for any claim. Dellonda Limited Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR 01284 757575 support@dellonda.co.uk...
