User Manual
Mobile Signal Booster
This manual is applicable to the
following products
dual band
33F series
(single/dual/tri-band)
1.1 Connector Instruction
The product has two antenna ports and a power
interface.
>>
BTS
Stands for the
outdoor end,
used to receive
signals from the
base station and
connect to
outdoor antennas.
1.2 Antenna Optional
Standard full set
Tri-band
1.outdoor antenna
3.indoor antenna
Outdoor Series
Outdoor LPDA antenna
User Manual
MS
Stands for indoor
end, connected
to indoor ceiling
SYS1
SYS2
SYS3
or wall-mounted
antenna.
AC+220V
Connect to 220V mains
2.signal repeater
4.coaxial cable
Accessories display
Ceiling antenna
Cable
User Manual
Eight unit Yagi antenna
Power supply
1.3 Attenuation Instructions
Digital attenuation
Press the "+" or "-" attenuation
Attenuation up to 31dB
Simulated attenuation
The attenuation of the ATT corresponding to the DIP switch:
1 → 1dB 2 → 2dB 3 → 4dB 4 → 8dB 5 → 16dB at most 31Db,
6 → 1dB 7 → 2dB 8 → 4dB 9 → 8dB 10 → 16dB at most 31dB
User manual
Advertisement
Table of Contents
Summary of Contents for JTD SYS
- Page 1 User Manual User Manual User Manual 1.1 Connector Instruction The product has two antenna ports and a power interface. Mobile Signal Booster >> Stands for indoor This manual is applicable to the Stands for the end, connected Eight unit Yagi antenna Power supply User manual outdoor end,...
- Page 2 2.1 Device Connection Mobile signal Repeater (side) Mobile Signal Repeater installation includes mounting Run SYS-3 SYS-2 SYS-1 Reset brackets,retransmission antennas,power supplies,etc. Simple on-site installation, design mounting bracket on the back of the product, can be directly mounted on the wall.
