- Page 1 A 5 9 . 3 5 2 1 10.5" Touch Screen Android Pad Digital Camera, 8.0M Instruction Manual Please read this manual carefully before use microscope & digital camera! www.optoedu.com 1 / 8 sale@optoedu.com...
-
Page 2: Specification
⚫ Android 11 Tablet Built-in Memory RAM 2G + ROM 16G For Photo & Video Record ⚫ USB3.0+HDMI+LAN Output, Touch Screen + USB Mouse & Keyboard Control ⚫ Open & See Microscope Image Directly, Built-in Software For Measure & Analysis Specification A59.3521 10.5" Touch Screen Android Pad Digital Camera, 8.0M Model A59.3521 Category HD All-in-One Android 11 System Tablet Digital Camera 1/1.8”... -
Page 3: Operation
USB 2.0*1 USB 3.0*2 HDMI DC-12V Power On C-Mount Operation 1. First, connect the tablet to DC-12V power adapter 2. Then connect the tablet to microscope by standard C-Mount. (See how to connect digital camera to microscope at end of this manual.) 3. -
Page 4: Main Interface
S-Eye Software Introduction Main Interface The camera & tablet will enter the main interface directly after power on, and you can click the shortcut buttons on the bottom of screen to set, take photo, record video, review, measure, zoom in/out, mirror image, flip image, etc. as needed. Setting, Photo Capture, Video Record, Preview, Measurement. -
Page 5: Setting Mode
Setting Mode 1, After the camera is turned on directly into the screen as shown 2, Click button to pop up the setting menu as above picture 3, Set the image parameters according to demand (1) Auto Exposure: Manual Setting and Auto Setting (Default). (2) White Balance: Automatic (Default) and One-touch Set. -
Page 6: Calibration Setting
Calibration Setting Click to choose the button to enter measure calibration mode. 1. mode: providing calibration mode, line calibration and circle calibration are available to be selected. After clicking the line calibration icon, the preview interface will directly display the line segment, according to the location and length of the calibration scale, the mouse will move the line segment to the top of the calibration scale to overlap with the corresponding scale. -
Page 7: Measure Mode
Measure Mode Click to enter measure mode, you can measure the objects, capture screenshot for report. Point coordinates, straight line, dashes (end of right mouse button), drawing circle etc. 2 Points Circle, 3 Points Circle, Concentric Circles, Circle Center Distance. Polygon, Rectangle, Angle, Point-Line Distance, Text Mark Set Graph Color &... - Page 8 A59.3521 Size & Diaphragm ADD: F-1501 Wanda Plaza No.18 Shijingshan Road, Beijing 100043, China Note: No additional notice for TEL: 0086-10-88696020 changes on the specification or ZIP: 100043 appearance due to upgrade. E-mail: sale@optoedu.com www.optoedu.com 8 / 8 sale@optoedu.com...
