Quick Start Guide
VE2A02 Venation E2 IoT Gateway
無線智能物聯網閘道器
Venation E2 IoT Gateway provides Wi-Fi and Z-Wave connectivity and IP networking capability for controlling and
communicating with IoT sensors and IP devices. The gateway brings the most flexible wireless extensions as
integrating different brands of wireless devices into an automated Modbus/TCP network.
Advertisement
Related Manuals for Ardomus Venation E2
Summary of Contents for Ardomus Venation E2
- Page 1 VE2A02 Venation E2 IoT Gateway 無線智能物聯網閘道器 Venation E2 IoT Gateway provides Wi-Fi and Z-Wave connectivity and IP networking capability for controlling and communicating with IoT sensors and IP devices. The gateway brings the most flexible wireless extensions as integrating different brands of wireless devices into an automated Modbus/TCP network.
-
Page 2: Installation Prerequisites
Installation Prerequisites Venation E series have GUI (Graphic User Interface) service for users to pair wireless devices, set up data conversion and regarding internet configuration. Please make sure the Venation E series and commissioning tool are in the same LAN (Local Area Network). Material 1. -
Page 3: Pairing Devices
User Name: admin Password: 1234 Pairing Devices Page: Device Center > Devices > Z-Wave Click the “Add Device” to start the pairing process. Venation E series will automatically discover un-pairing devices nearby. - Page 4 Mapping Data Points Page: Virtual Domain > Mapping Table After devices paired, clicking “Auto Mapping” Venation E series could convert Z-Wave endpoints into Modbus Register automatically.
- Page 5 Edit Modbus Register Format Page: Device Center > Devices > Export Device This page lists automatically converted Modbus registers, click Pencil icon to edit register format.
-
Page 6: Network Configuration
Network Configuration Venation E series get IP settings automatically using DHCP, however you could set up static IP as per needs. Page: > Settings > Network... - Page 8 Venation E series get IP settings automatically using DHCP via Wifi Page: > Settings > Wifi Select your wifi SSID and key in password, then device will get IP from wireless.
-
Page 10: Safety Guidelines
Safety Guidelines The following guidelines help ensure your safety and protect the services gateway from damage. The list of guidelines might not address all potentially hazardous situations in your working environment, so be alert and exercise good judgment at all times. ●... - Page 11 ● Avoid spilling liquid onto the services gateway chassis or onto any services gateway component. Such an action could cause electrical shock or damage the services gateway. ● Avoid touching uninsulated electrical wires or terminals that have not been disconnected from their power source.
- Page 12 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. For 2.4G WLAN, only channel 1 – 11 are operational. Selection of other channels is NOT possible. IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
- Page 13 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及 功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續 使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 本機現在不干擾合法電台與不被干擾保障條件下於室內使用，本產品使用時建議應距離人體 20cm。...
