- Page 1 MODEL / MODELO TY-1001 TIRE PRESSURE MONITORING SYSTEM SISTEMA DE MONITOREO DE PRESIÓN NEUMÁTICA OWNERS MANUAL / MANUAL DEL USUARIO Questions ? Help Call customer service hotline 877-456-7901. SAVE THIS OWNERS MANUAL AND READ BEFORE USE. CONSERVE ESTE MANUAL DEL USUARIO Y LEALO ANTES DE USO.
-
Page 2: Table Of Contents
CONTENTS SAVE THESE INSTRUCTIONS CONTENTS DIGITAL DISPLAY INSTALLING THE SENSORS SETUP THE DISPLAY WARNINGS AND ALARMS REPLACING THE BATTERIES SPECIFICATIONS FCC INFORMATION... -
Page 3: Save These Instructions
SAVE THESE INSTRUCTIONS Read manual before installing product. Save installation kit and store near unit. Check condition of tires regularly. If tires are removed for service, reinstall the sensors on the location marked on each sensor. This system monitors tire pressure and temperature, but does not prevent accidents. -
Page 4: Installing The Sensors
INSTALLING THE SENSORS Note: The sensors have been pre-assigned to corresponding tires. - Sensor FL means for "Front Left Tire" - Sensor FR means for "Front Right Tire" - Sensor RL means for "Rear Left Tire" - Sensor RR means for "Rear Right Tire" Before installation, plug the display into the car's 12V socket and start the engine. -
Page 5: Setup The Display
SETUP THE DISPLAY Plug the display into the car's 12V socket and start the engine. NOTE: The sensors have been pre-programmed with values appropriate for most vehicles. Switch Between Tire Pressure or Temperature On Display 1. Default setting shows tire pressure. 2. - Page 6 High/Low Pressure value Setting Low pressure 1. Switch to show tire pressure on display. 2. Press and hold control button for five seconds, the unit in upper left flashes represents low pressure value and now is ready for being adjusted. 3.
-
Page 7: Warnings And Alarms
WARNINGS AND ALARMS High pressure warning When tire pressure exceeds the default high value (46 PSI). Alarm beeps, corresponding unit and indicator flashes. Low pressure warning When tire pressure falls below default low value (26 PSI). Alarm beeps, corresponding unit and indicator flashes. -
Page 8: Replacing The Batteries
Low battery warning When a sensor battery is low, corresponding unit will show "Lo" and flashes, indicator will flash as well. Please replace the battery as soon as possible. No sensor signal If battery of sensor is running out or sensor is damaged. -
Page 9: Specifications
SPECIFICATIONS DISPLAY UNIT Operating frequency FSK 433.92 mHz ± 30 kHz Operating voltage 2.2-3.0 V Operating current (USB no load) 50-70 mA Operating temperature -4˚- +176˚ F USB output voltage USB output current 2.1A TIRE PRESSURE SENSOR Operating frequency FSK 433.92 mHz ± 30 kHz Operating voltage 2.2 - 3.0 V Operating current... -
Page 10: Fcc Information
FCC INFORMATION This product is FCC certified. FCC ID: 2APJX-TY1001. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules.
